Description
|
item
|
value
|
|
Place of Origin
|
Shanghai, China
|
|
Brand Name
|
SK(shangkai) Yongxing
|
|
Model Number
|
KCD8-11N-CB1A-B-G-01
|
|
Current Rating
|
6A
|
|
Voltage Rating
|
250V AC
|
|
Mechanical Life
|
50000 Cycles
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥1000MΩ
|
|
Dielectric Strength
|
1500VAC 1 Minute
|
|
Electronic Life (cycles)
|
10,000
|
|
Certificate
|
CQC CE CB ENEC17 UL ROHS
|
|
Circuit
|
SPST LED Lighted
|
|
Dimension Code
|
B1
|
|
Contact Piece Code
|
A
|
|
Lamp voltage
|
6v/12v/24v/110v/220v
|
Why Choose Our LED Rocker Switch?
Our LED Rocker Switch stands out for its superior quality, durability, and versatility. Made from high-quality plastic, it ensures long-lasting performance even in demanding environments. The SPST ON-OFF LED illuminated design provides clear indication of the switch status, enhancing user experience. With a wide range of colors available, you can easily find the perfect match for your application.
What Are the Key Features?
Key features include a maximum current of 6A and a voltage rating of 250V AC, making it suitable for a variety of electric equipment. It has a mechanical life of 50,000 cycles and an electronic life of 10,000 cycles, ensuring reliable operation over time. Additionally, it offers low contact resistance (≤50mΩ) and high insulation resistance (≥1000MΩ), providing safety and efficiency. The switch is also IP41 and IP65 rated, making it suitable for various environments.
What Are the Advantages of Buying from Us?
As a direct factory supplier and wholesaler, we offer competitive prices without compromising on quality. We are committed to providing excellent after-sales service, ensuring your satisfaction. Our LED Rocker Switch is designed to meet the highest standards, making it a reliable choice for your electric equipment needs. Choose us for superior quality, competitive pricing, and exceptional service.
