Description
Product Specifications:
– Place of Origin: Shanghai, China
– Brand Name: Sk(shangkai) Yongxing
– Model Number: LA133-B1.J-K11 R
– Protection Level: IP40, IP65, IP67
– Max. Current: 10A
– Max. Voltage: 660 VAC
– Rated Insulation Voltage: 660v AC
– Rated Thermal Current: 10A
– Max. Insulation Voltage: 2500 V/min
– Usage Category: AC-15, DC-13
– Mechanical Life: 1,000,000 cycles
– Operation Frequency: 1200 cycles/h
– Electrical Life for AC-15: 600,000 cycles
– Electrical Life for DC-13: 250,000 cycles
– Material: PA66
– Size: 22mm
– Rated Voltage: 660V
Our switch stands out from competitors with its durable PA66 material, ensuring long-lasting performance. The high mechanical and electrical life ratings guarantee reliability in demanding environments. Additionally, the IP40, IP65, and IP67 protection levels provide excellent resistance to dust and water ingress. As a factory direct supplier, we offer customization options, including private labeling, to meet your specific needs.
We pride ourselves on providing excellent customer service and after-sales support. Our team is available to assist with any questions or concerns you may have. Choose our Factory Direct Wholesale 22mm 1NO1NC Self-Locking Emergency Stop Button Switch for a reliable, cost-effective solution that meets your industrial safety requirements.
|
item
|
value
|
|
Place of Origin
|
Shanghai,China
|
|
Brand Name
|
Sk(shangkai) yongxing
|
|
Model Number
|
LA133-B1.J-K11 R
|
|
Protection Level
|
IP40 IP65 IP67
|
|
Max. Current
|
10A
|
|
Max. Voltage
|
660 VAC
|
|
Rated Insulation Voltage
|
660v ac
|
|
Rated Thermal Current
|
10A
|
|
Max.insulation voltage
|
2500 V/min
|
|
Usage Category
|
AC-15 DC-13
|
|
Mechanical Life
|
1000,000
|
|
Operation frequency
|
1200 cycles/h
|
|
Electrical life for AC-15
|
600000 cycles
|
|
Electrical life for DC-13
|
250000 cycles
|
|
Mounting Hole Size
|
22mm Diameter
|
Why Choose Our Emergency Stop Button Switch?
Our Factory Direct Wholesale 22mm 1NO1NC Self-Locking Emergency Stop Button Switch is designed with safety and reliability in mind. The self-locking mechanism ensures that once activated, the switch remains in the stopped position until manually reset, providing an extra layer of safety in emergency situations. This feature is crucial in industrial settings where immediate shutdown is necessary to prevent accidents or damage.
What Makes Our Switch Stand Out?
Unlike many competitors, our switch is made from high-quality PA66 material, known for its durability and resistance to wear and tear. This ensures a long service life, even in harsh environments. Additionally, the switch offers multiple protection levels (IP40, IP65, IP67), making it suitable for a wide range of applications. The high mechanical and electrical life ratings further enhance its reliability, reducing the need for frequent replacements.
What Support Do We Offer?
As a factory direct supplier, we offer competitive wholesale prices and excellent customer service. We understand the importance of timely delivery and quality assurance, which is why we provide rigorous testing and inspection before shipping. Our team is also available to assist with any customization needs, such as private labeling, to help you differentiate your products in the market. Choose our switch for a reliable, cost-effective solution that meets your industrial safety requirements.
