Factory Direct Wholesale 3-Position Small Power Rotary Switch with CQC Certification

2,000 - 4,999  pieces
$0.50

>= 5,000  pieces
$0.45

0 reviews

Factory wholesale 3-position rotary switch, CQC certified, high quality, customizable.

Description

Looking for a reliable and high-quality small power rotary switch? Look no further! We are a factory supplier offering wholesale 3-position rotary switches with CQC certification. Our switches are designed to meet the highest standards of performance and durability.

Product Specifications

  • Brand Name: Yongxing
  • Model Number: RS1
  • Max. Current: 6A
  • Max. Voltage: 250V AC
  • Contact Resistance: ≤50mΩ
  • Insulation Resistance: ≥100mΩ
  • Dielectric Resistance: 1500V
  • Electronic Life: 10,000 cycles
  • Mechanical Life: 100,000 cycles
  • IP Level: IP41
  • Operating Temperature: T125

Product Advantages

Our rotary switches stand out from the competition with their exceptional quality and performance. We have our own independent plant, injection workshop, and advanced experimental equipment. With over 60 senior engineers, we ensure that every switch meets the highest standards. All our workshops adhere to 5S and 5M management standards, guaranteeing consistent quality.

Customization and Wholesale

We offer customization services to meet your specific requirements. If you have a large quantity order, we can tailor the rotary switch to your needs. As a factory supplier, we provide competitive wholesale prices, making it an excellent choice for bulk purchases.

After-Sales Service

We stand behind our products with excellent after-sales service. If you encounter any issues, our dedicated team is here to assist you promptly.

max.rating cnrrent&voltage
6a 250vac
contact resistance
<50mΩ
insulation resistance
>100mΩ
dielectrice resistance
1500V
electronic life
10000
operating temperature
T125
CQC,ENEC

Electronic component for cross-border e-commerceElectronic device image for e-commerceElectronic product display for e-commerce


Key Features and Benefits

Our 3-position small power rotary switch is designed for high performance and reliability. With a maximum current of 6A and a voltage of 250V AC, it is suitable for a wide range of applications. The switch's IP41 rating ensures protection against dust and water, making it ideal for industrial environments.

Why Choose Our Rotary Switch?

As a factory supplier, we offer competitive prices and high-quality products. Our switches are CQC certified, ensuring they meet international safety standards. With a mechanical life of 100,000 cycles and an electronic life of 10,000 cycles, our switches are built to last.

Customization and Support

We understand that every customer has unique requirements. That's why we offer customization services to tailor the rotary switch to your specific needs. Our dedicated after-sales team is always available to provide support and resolve any issues you may encounter.

Push Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch Customized

Additional information

Whether the smart

NO

Max. Current

6A

Max. Voltage

250V AC

Place of Origin

Shanghai, China

Brand Name

Yongxing

Model Number

RS1

Mechanical Life

100,00 cycles

IP level

IP41

Contact Resistance

≤50mΩ

Insulation resistance

≥100mΩ

dielectric resistance

1500V

electronic life

10000 cycles
