Factory Direct Wholesale IP40 16mm Red/Green LED Push Button Switch

1,000 - 1,900  pieces
$0.42

>= 2,000  pieces
$0.40

0 reviews

Factory Direct Wholesale IP40 16mm LED Push Button Switch – High Quality, Reliable, Customizable.

Description

As a professional factory and supplier, we are proud to offer our high-quality IP40 16mm Red/Green LED Push Button Switch for wholesale. This switch is designed with precision and durability in mind, making it ideal for a wide range of applications, including home appliances, industrial machinery, and more. Our switch features a contact resistance of ≤50mΩ, insulation resistance of ≥100MΩ, and dielectric strength of 1500V, ensuring reliable performance under various conditions. With an electronic life of 10,000 cycles (momentary) and 5,000 cycles (alternate), as well as a mechanical life of 50,000 cycles (momentary) and 100,000 cycles (alternate), our switch offers exceptional longevity. It operates within a temperature range of -25°C to +55°C and is rated for 1A/250V AC, with CQC and CE certifications. Our switch stands out with its bright LED indicators, available in red and green, providing clear visual feedback. As a factory-direct supplier, we offer competitive pricing and the flexibility to customize the switch to meet your specific needs. Choose our IP40 16mm Red/Green LED Push Button Switch for quality, reliability, and value.
Contact resistance ≤50mΩ
Insulation resistance ≥100MΩ
Dielectric strength 1500v
Electronic life (cycles) Moment:10000 Alternate:5000
Mechanical life (cycles) Moment:50000 Alternate:100000
Operating temperature 25T55
IP code IP40
Max.Rating Current&Voltage 1A/250V AC
Certification CQC, CE

Electronic component product image for cross-border e-commerceElectronic device product image for cross-border e-commerce


Why Choose Our IP40 16mm Red/Green LED Push Button Switch?

Our switch is designed to meet the rigorous demands of industrial and home appliance applications. With its IP40 protection rating, it ensures reliable operation in dusty environments. The bright red and green LED indicators provide clear visual feedback, enhancing user experience. The switch's high mechanical and electronic life means fewer replacements and lower maintenance costs over time.

What Makes Our Switch Stand Out?

As a factory-direct supplier, we offer competitive pricing without compromising on quality. Our switch is customizable to meet your specific needs, whether it's a different color LED, a unique switch configuration, or special certifications. We also provide excellent after-sales service, ensuring your satisfaction with our product.

Applications and Compatibility

Our IP40 16mm Red/Green LED Push Button Switch is ideal for use in home appliances, industrial machinery, control panels, and more. Its compact size and robust design make it suitable for a wide range of applications. Whether you're looking for a standard switch or a customized solution, we have you covered.

Push Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch Customized

Additional information

Max. Current

1A

Max. Voltage

250VAC

Place of Origin

Shanghai, China

Brand Name

Yongxing

Model Number

FD16-121L2D

LED

Yes

Whether the smart

NO

IP level

IP40

Switch Combination

1NO1NC, 1NO

Operating temperature

-25 ℃~+55℃

Electronic life(cycles)

Moment:10,000 Alternate:5,000

Mechanical life(cycles)

Moment:50,000 Alternate:10,000

Insulation resistance

100MΩ

Dielectric Stength

1,500V

Contact Resistance

50m Max

Insulation Resistance

100M Min

Protection Level

IP40
