Description
| Panel Thickness | 1-10mm |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥1000 MΩ 4 pin push button switch |
| Torque | 5-14Nm |
| Operating Pressure | About 4N |
| Operating Stroke | About 1.8mm |
| Mounting Hole Size | 22mm |
| Dielectric Strength | 2000VAC |
| Electronic Life | >1,000,000 times |
| Mechanical Life | >200,000 times |
| Operating temperature | -20°c~+55°c |
| IP code | IP67 IK09 |
| Switch Rating | 2A /36VAC emergency push button switch |
| Contact Configuration | 1NO |
| Operating Type | Momentary elevator push button switch |
| The Front Shape | High Round |
| The Crust Material | Stainless Stell,Nickel-plated Brass or Gold-Plated Brass |
|
Material |
Contact : Sliver Alloy (Can be made to order) |
Why Choose Our Momentary 1NO1NC LED Push Button Switch?
Our Momentary 1NO1NC LED Push Button Switch stands out due to its high-quality construction, featuring stainless steel, nickel-plated brass, or gold-plated brass for the crust, and silver alloy for the contacts. The LED indicator provides clear visual feedback, and the IP67 waterproof rating ensures durability in harsh environments. With a long mechanical and electrical life, this switch is built to last.
What Are the Key Features of Our Switch?
Key features include a 16MM dome button, 2Pin screw terminals, momentary action, and a rated voltage of 250V with a maximum current of 5A. The switch also offers customization options to meet your specific needs, making it a versatile choice for various applications.
How Can You Benefit from Our Factory Wholesale Pricing?
As a factory supplier, we offer competitive pricing and fast delivery on our Momentary 1NO1NC LED Push Button Switch. By purchasing directly from us, you can save on costs and ensure a reliable supply of high-quality switches for your business needs.
