Description
Key Features:
– Max. Current: 16A
– Max. Voltage: 250VAC
– Mechanical Life: 50,000 Cycles
– Electrical Life: Min 10,000 Cycles
– IP Level: IP65
– Certifications: CQC, CE, UL, CB, ENEC
– Customizable Pins: 2P, 3P (with options for 4P, 6P)
– LED Color Options: Orangered, Blue, Green, White
– Housing Color: Black (customizable)
Why Choose Us?
– Factory Direct: Skip the middleman and get the best prices.
– Wholesale Supplier: Perfect for bulk orders.
– Customization Available: Tailor the switch to your specific needs.
– Advanced Facilities: Independent plant, injection workshop, and advanced experimental equipment.
– Expert Team: Over 60 senior engineers ensuring top-notch quality.
Whether you’re in need of a standard switch or a customized solution, we’ve got you covered. Contact us today for a quote and experience the difference of working with a factory-direct supplier.
| max.rating cnrrent | 16A | dielectrice resistance | 1500V |
| max.rating voltage | 250V | electronic life | 10000cycles |
| contact resistance | 50mΩ | operating temperature | T55,T85,T125 |
| insulation resistance | 1000mΩ | certifications | CQC,CE,UL,CB,ENEC |
| housing color | black(selective) | button color | black(selective) |
| PIN number | 3 (selective2,3,4,6) | lamp voltage | 6V,12V,24V,110V,220V |
Why Choose Our Rocker Switch?
Our rocker switch stands out for its durability, reliability, and customization options. Made from high-quality PA66 material, it ensures long-lasting performance in various electric equipment applications.
What Are the Key Features?
Key features include a max. current of 16A, max. voltage of 250VAC, mechanical life of 50,000 cycles, and electrical life of at least 10,000 cycles. It also offers IP65 protection, making it suitable for harsh environments.
Can I Customize the Switch?
Absolutely! As a factory-direct supplier, we offer customization options to meet your specific needs. Choose from different pin configurations, LED colors, and housing colors to create the perfect switch for your application.
