Description
Our switch boasts a momentary operating type, ensuring precise control with each press. It has a high round front shape and a mirror surface with a CD pattern, adding a touch of elegance to any device. The switch is equipped with a silver alloy contact and a PBT base, guaranteeing excellent conductivity and stability.
Key specifications include a contact resistance of ≤50mΩ, insulation resistance of ≥1000MΩ, and a dielectric strength of 2000VAC. It can withstand an operating temperature range of -20℃ to +55℃, ensuring reliable performance in various conditions. With a mechanical life of over 1,000,000 times and an electrical life of over 200,000 times, this switch is built to last.
As a trusted supplier, we offer competitive wholesale prices and customizable options to meet your specific needs. Whether you’re looking for a standard 1NO configuration or a custom switch combination, we’ve got you covered. Place your order today and experience the quality and reliability of our factory-direct products.
| Panel Thickness | 1-10mm |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥1000 MΩ 4 pin push button switch |
| Torque | 5-14Nm |
| Operating Pressure | About 4N |
| Operating Stroke | About 1.8mm |
| Mounting Hole Size | 22mm |
| Dielectric Strength | 2000VAC |
| Electronic Life | >1,000,000 times |
| Mechanical Life | >200,000 times |
| Operating temperature | -20°c~+55°c |
| IP code | IP67 IK09 |
| Switch Rating | 2A /36VAC emergency push button switch |
| Contact Configuration | 1NO |
| Operating Type | Momentary elevator push button switch |
| The Front Shape | High Round |
| The Crust Material | Stainless Stell,Nickel-plated Brass or Gold-Plated Brass |
|
Material |
Contact : Sliver Alloy (Can be made to order) |
Why Choose Our Waterproof Metal Push Button Switch?
Our Waterproof Metal Push Button Switch stands out for its durability, reliability, and versatility. With an IP67 IK09 rating, it offers superior protection against water and impact, making it ideal for outdoor and industrial environments. The stainless steel, nickel-plated brass, or gold-plated brass crust ensures long-lasting performance, while the silver alloy contact and PBT base guarantee excellent conductivity and stability.
What Are the Key Features of Our Switch?
Our switch features a momentary operating type for precise control, a high round front shape with a mirror surface and CD pattern for added elegance, and customizable options to meet your specific needs. It also boasts a long mechanical and electrical life, ensuring reliable performance over time.
How Can I Benefit from Buying Wholesale?
As a factory-direct supplier, we offer competitive wholesale prices and customizable options. By buying in bulk, you can save money and ensure a steady supply of high-quality switches for your projects. Place your order today and experience the difference our Waterproof Metal Push Button Switch can make.
