Description
|
item
|
value
|
|
Place of Origin
|
Shanghai, China
|
|
Brand Name
|
SK(shangkai) Yongxing
|
|
Model Number
|
KCD1-11N-CA5C-B-R-01-AC220
|
|
Current Rating
|
16A
|
|
Voltage Rating
|
250V AC
|
|
Mechanical Life
|
50,000 Cycles
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥1000MΩ
|
|
Dielectric Strength
|
1500VAC 1 Minute
|
|
Electronic Life (cycles)
|
10,000
|
|
Certificate
|
CQC CE CB ENEC17 ROHS
|
|
Circuit
|
SPST illuminated
|
|
Dimension Code
|
A5 28x11mm
|
|
Contact Piece Code
|
C 6.3X0.8X10mm standard
|
|
Lamp voltage
|
AC220V
|
Why Choose Our Yongxing KCD1 Rocker Switch?
Our Yongxing KCD1 Rocker Switch stands out for its high-quality construction, offering a 16A current rating and 250V AC voltage capacity, making it ideal for a wide range of electronic applications. The switch features a red illuminated rocker, enhancing visibility and ease of use, especially in low-light conditions. With a mechanical life of 50,000 cycles and an electronic life of 10,000 cycles, it ensures long-lasting reliability and performance.
What Are the Key Features of Our Switch?
Key features include its compact 28x11mm dimension, 3-pin configuration, and IP65 rating, which provides protection against dust and water. The switch also boasts excellent insulation resistance (≥1000MΩ) and contact resistance (≤50mΩ), ensuring safe and efficient operation. Additionally, it supports a wide operating temperature range, making it suitable for various environments.
How Does Our Factory Direct Wholesale Benefit You?
As a factory supplier, we offer competitive wholesale prices, eliminating the middleman and passing on the savings to you. Our direct access to production ensures high-quality standards and timely delivery. Moreover, we provide excellent after-sales service, ensuring your satisfaction and peace of mind. Choose our Yongxing KCD1 Rocker Switch for reliable, efficient, and cost-effective performance in your electronic projects.
