Factory Wholesale 10A 250VAC Self-Latching Push Button Switch with 12VDC LED Indicator

200 - 1,999  pieces
$0.62

2,000 - 4,999  pieces
$0.59

>= 5,000  pieces
$0.56

0 reviews

Factory Wholesale 10A 250VAC Push Button Switch with LED. Durable, reliable, and competitively priced.

Description

Our Factory Wholesale 10A 250VAC Self-Latching Push Button Switch with 12VDC LED Indicator is a high-quality, reliable electrical component designed for a wide range of applications. As a direct supplier from the factory, we offer competitive wholesale prices without compromising on quality. This switch features a robust black housing with a vibrant red button, making it both durable and aesthetically pleasing. With a maximum rating of 10A at 250V AC and a 12VDC LED indicator, it’s perfect for indicating power status in various devices. The switch has a mechanical life of 20,000 cycles and an electronic life of 10,000 cycles, ensuring long-lasting performance. It operates within a temperature range of -25℃ to +85℃, making it suitable for use in harsh environments. The IP40 protection level provides adequate dust resistance, while the pin terminal type ensures easy installation. Our switch stands out with its self-latching mechanism, which maintains the switch position without continuous pressure, and the bright LED indicator that clearly shows the power status. Choose our factory-direct, wholesale-priced push button switch for your next project and experience the difference in quality and value.
contact resistance
≤50MΩ
mechanical life(cycles)
20000
insulation resistance
≥100MΩ
electronic life(cycles)
10000
dielectric strength
1500V 1min
operating temperature
25T85
IP code
IP40
max.rating current & voltage
10(3)A 250V AC

Electronic component for cross-border e-commerce


Why Choose Our Push Button Switch?

Our push button switch stands out for its durability, reliability, and competitive pricing. As a factory supplier, we offer wholesale rates without sacrificing quality. The self-latching mechanism and bright LED indicator make it ideal for a wide range of applications, from industrial control to home appliances.

What Are the Key Features?

Key features include a 10A 250VAC rating, 12VDC LED indicator, IP40 protection level, and a mechanical life of 20,000 cycles. The switch also boasts high insulation resistance and a normally open circuit, ensuring safe and efficient operation.

How Does It Compare to Other Products?

Compared to other switches on the market, our product offers superior durability and a longer mechanical life. The self-latching mechanism and LED indicator provide added convenience and functionality, making it a preferred choice for many applications.

Push Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch Customized

Additional information

Max. Current

10A/16A

Max. Voltage

250V AC

Place of Origin

Shanghai, China

Brand Name

Yong Xing

Model Number

KA22-11L-AAA

LED

Yes

Whether the smart

NO

IP level

IP40

Switch Combination

1NO1NC

Name

KA22-11L-AAA

color

black housing, red button

Circuit

Normally open, 1NO

LED Voltage

12vdc red

Terminal Type

Pin terminal

Mechanical life

20000cycles

Electronic life

10000cycles

Operating temperature

-25℃~+85℃

Insulation Resistance

≥100mΩ

Color

Orange

Protection Level

IP40
