Description
| Max. Rating Current & Voltage (Resistive Load) |
3A 250V AC indicator light |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥100MΩ 220 volt led indicator lights |
| Dielectric Resistance | 1,500V |
| Electronic life(cycles) | Momentary:50,000 Alternate:25,000 |
| Mechanical life(cycles) | Momentary:200,000 Alternate:50,000 |
| Certification |
CQC , CE |
| Operating temperature | -5℃~+75℃ |
| IP code | IP40 |
Why Choose Our Push Button Switch?
Our push button switches are designed for durability and reliability, with a long mechanical life of up to 200,000 cycles. They feature a momentary action, making them ideal for applications where a temporary connection is needed. The LED indicator light provides clear visual feedback, enhancing user experience.
What Are the Key Specifications?
Our switches come in 10mm, 12mm, and 16mm sizes, with a maximum rating current of 3A and a voltage of 250V AC. They have a contact resistance of ≤50mΩ and an insulation resistance of ≥100MΩ, ensuring efficient and safe operation. The LED indicator light is available in multiple colors, and the switches are CQC, CE, and RoHS certified.
Where Can Our Switches Be Used?
Our push button switches are suitable for a wide range of applications, including industrial controls, automation systems, and electrical equipment. Their durable design and reliable performance make them a popular choice among professionals in various industries.
