Description
Key Specifications:
- Size: 10mm
- Max. Current: 3A
- Max. Voltage: 250VAC
- LED Colors Available: Red, Green, Yellow, Blue, Orange, White
- Contact Resistance: ≤50mΩ
- Dielectric Strength: 1500V
- Operating Temperature: -5℃~+75℃
- Protection Level: IP40
- Certification: CQC, CE
Our switch stands out with its long mechanical life (up to 200,000 cycles for momentary action) and electronic life (up to 50,000 cycles for momentary action). It’s perfect for use in control panels, machinery, and other industrial applications where reliability and durability are crucial.
As a direct supplier and factory, we offer competitive pricing and flexible wholesale options. Whether you’re looking to stock up on inventory or need a large order for a project, we’ve got you covered. Contact us today to learn more about our 10mm LED plastic push button switch and how it can benefit your business.
| Max. Rating Current & Voltage (Resistive Load) |
3A 250V AC indicator light |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥100MΩ 220 volt led indicator lights |
| Dielectric Resistance | 1,500V |
| Electronic life(cycles) | Momentary:50,000 Alternate:25,000 |
| Mechanical life(cycles) | Momentary:200,000 Alternate:50,000 |
| Certification |
CQC , CE |
| Operating temperature | -5℃~+75℃ |
| IP code | IP40 |
Why Choose Our 10mm LED Plastic Push Button Switch?
Our 10mm LED plastic push button switch is designed for durability and reliability, making it ideal for industrial applications. With a long mechanical and electronic life, it ensures consistent performance over time.
What Are the Key Features of This Switch?
Key features include a bright LED indicator light, multiple color options, and compliance with CQC and CE certifications. It also offers excellent contact and dielectric resistance, ensuring safe operation.
Can I Buy This Switch in Bulk?
Yes, as a factory supplier, we offer wholesale options for our 10mm LED plastic push button switch. Contact us for competitive pricing and flexible order quantities.
