Description
| Max. Rating Current & Voltage (Resistive Load) |
3A 250V AC indicator light |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥100MΩ 220 volt led indicator lights |
| Dielectric Resistance | 1,500V |
| Electronic life(cycles) | Momentary:50,000 Alternate:25,000 |
| Mechanical life(cycles) | Momentary:200,000 Alternate:50,000 |
| Certification |
CQC , CE |
| Operating temperature | -5℃~+75℃ |
| IP code | IP40 |
Why Choose Our Push Button Switch?
Our push button switches are designed for durability and reliability, featuring a plastic lamp body and precise contact resistance. With LED indication in multiple colors, they offer clear visual feedback, making them ideal for engine start/stop, slot machines, and various control applications.
What Are the Key Features?
Key features include a momentary on/off action, NO/NC configurations, and a maximum rating of 3A 250V AC. They also boast a dielectric strength of 1500V, ensuring safety and reliability in demanding environments.
Why Buy from Us?
As a direct factory supplier, we offer competitive pricing and bulk purchase options. Our switches are certified by CQC and CE, ensuring quality and compliance with international standards. Trust in our expertise and service for your next project.
