Description
| Max. Rating Current & Voltage (Resistive Load) |
3A 250V AC indicator light |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥100MΩ 220 volt led indicator lights |
| Dielectric Resistance | 1,500V |
| Electronic life(cycles) | Momentary:50,000 Alternate:25,000 |
| Mechanical life(cycles) | Momentary:200,000 Alternate:50,000 |
| Certification |
CQC , CE |
| Operating temperature | -5℃~+75℃ |
| IP code | IP40 |
Why Choose Our 12mm Latching Push Button Switch?
Our 12mm latching push button switch stands out for its versatility and reliability. With configurations of 1NO1NC or 2NO2NC, it can be tailored to meet the specific needs of your project. The switch supports a wide range of voltages and has a high current rating, ensuring stable performance under various conditions.
What Makes Our Switch Different?
Unlike other switches on the market, our product features a plastic lamp body that is both durable and lightweight. The indicator lights in multiple colors make it easy to identify different functions or states, enhancing user experience. Additionally, our switch is certified by CQC and CE, guaranteeing compliance with international safety standards.
Who Can Benefit from Our Switch?
Our 12mm latching push button switch is ideal for electrical control systems, automation systems, and industrial equipment. Whether you're a professional electrician or a hobbyist, our switch offers the quality and performance you need to get the job done right. As a factory supplier, we offer competitive wholesale prices, making it an affordable choice for businesses of all sizes.
