Description
12V 12mm LED Push Button Switch Latching Type – Wholesale Supplier
Introducing our high-quality 12V 12mm LED Push Button Switch with a latching type mechanism, perfect for a wide range of applications. As a factory direct supplier, we offer competitive wholesale prices without compromising on quality.
Product Specifications:
- Max. Current: 3A
- Max. Voltage: 250V AC
- LED Indicator: Yes, with indicator voltages of 2V, 6V, 12V, 24V, 110V, 220V
- Switch Combination: 1NO1NC, 2NO2NC
- Panel Cutout: 10mm
- Operating Temperature: -5℃~+75℃
- IP Level: IP40
- Certification: CQC, CE
Product Advantages:
Our LED push button switch stands out with its durable construction, reliable performance, and clear LED indication. The latching type mechanism ensures stable operation, while the IP40 protection level makes it suitable for various environments. As a trusted supplier, we provide excellent after-sales service and support.
Why Choose Us?
As a factory direct supplier, we offer unbeatable prices and quality assurance. Our products are rigorously tested to meet international standards, ensuring reliability and durability. Whether you’re looking for a single unit or bulk orders, we’ve got you covered. Contact us today for wholesale inquiries!
| Max. Rating Current & Voltage (Resistive Load) |
3A 250V AC indicator light |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥100MΩ 220 volt led indicator lights |
| Dielectric Resistance | 1,500V |
| Electronic life(cycles) | Momentary:50,000 Alternate:25,000 |
| Mechanical life(cycles) | Momentary:200,000 Alternate:50,000 |
| Certification |
CQC , CE |
| Operating temperature | -5℃~+75℃ |
| IP code | IP40 |
Product Functions
Our 12V 12mm LED Push Button Switch with latching type mechanism offers precise control and clear indication. The LED lights up when activated, providing visual feedback. The latching feature ensures the switch remains in the desired position until manually toggled.
Product Advantages
This switch stands out for its durability, reliability, and clear LED indication. The IP40 protection level makes it suitable for various environments, and the latching type mechanism ensures stable operation. As a factory direct supplier, we offer competitive prices and excellent after-sales service.
Why Choose This Product?
Choose our LED push button switch for its quality, performance, and affordability. Whether you're upgrading existing equipment or starting a new project, our switch is the perfect choice. Contact us today to learn more about our wholesale options!
