Description
Product Specifications:
- Max. Rating Current & Voltage (Resistive Load): 6.5A/250V AC, 13A/125V AC
- Contact Resistance: ≤50mΩ
- Insulation Resistance: ≥100MΩ
- Dielectric Resistance: 1500V
- Electronic Life (Cycles): 10,000
- Operating Temperature: T150
- Certification: CQC, RoHS
- Mechanical Life: 100,000 cycles
- IP Level: IP41
- Color: Black
- Poles: SP (Single Pole)
Product Advantages:
Our 1500V Oven Rotary Switch is engineered to withstand high temperatures and voltage, ensuring long-lasting durability and safety. With a mechanical life of 100,000 cycles, it offers superior reliability compared to many competitors. The switch’s compact design and easy installation make it a preferred choice for oven manufacturers.
After-Sales Service:
As a factory supplier, we provide comprehensive after-sales service, including technical support and warranty coverage. We are committed to ensuring your satisfaction and building a long-term partnership with you.
Wholesale & Bulk Orders:
We offer competitive wholesale prices for bulk orders. Whether you are a distributor, retailer, or OEM, we can meet your needs with flexible order quantities and fast delivery times.
|
Max. Rating Current&Voltage(Resistive load) |
6.5A/250V AC , 13A/125V AC |
| Contact Resistance of hot plate Rotary Switch | ≤50m Ω |
| Insulation Resistance | ≥100MΩ |
| Dielectric Resistance 4 position Rotary Switch | 1500V |
| Electronic life(cycles) | 10,000 |
| Operating temperature Rotary Switch | T150 |
| Certification |
CQC , Rohs |
Why Choose Our 1500V Oven Rotary Switch?
Our 1500V Oven Rotary Switch is designed to meet the rigorous demands of oven applications. With its high voltage and temperature resistance, it ensures safe and reliable operation, even in harsh environments. The long mechanical life and easy installation make it a cost-effective choice for oven manufacturers.
What Makes Our Product Stand Out?
Compared to other rotary switches on the market, our product offers superior durability and performance. The 1500V dielectric resistance and high insulation resistance ensure electrical safety, while the compact design and flexible poles make it adaptable to various oven models.
How Can We Support Your Business?
As a factory supplier, we offer competitive pricing for bulk orders and flexible order quantities. Our dedicated after-sales service team is always ready to provide technical support and resolve any issues you may encounter. Partner with us for a reliable and long-lasting business relationship.
