Description
|
item
|
value
|
|
Place of Origin
|
Shanghai, China
|
|
Brand Name
|
SK(shangkai) Yongxing
|
|
Model Number
|
KCD3-11-CA1H-W-W-01
|
|
Max. Current
|
10(3)A
|
|
Max. Voltage
|
250V AC
|
|
Mechanical Life
|
50000 Cycles
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥1000MΩ
|
|
Dielectric Strength
|
1500VAC 1 Minute
|
|
Electronic Life (cycles)
|
10,000
|
|
Certificate
|
CQC CE ROHS
|
|
Circuit
|
SPST mini ON OFF rocker switch t85
|
|
Dimension Code
|
A1 (21.7x15x15.8 , 19.1x13x13)
|
|
Contact Piece Code
|
H (7.5 length, 2.2×0.6 welding type)
|
|
Color
|
Red,Yellow,Green,Black,Blue,Orange,White,Gray
|
|
Function
|
On Off 2pin rocker switch panel
|
Why Choose Our Mini SPST Rocker Switch?
Our Mini SPST Rocker Switch stands out for its exceptional quality and reliability. With a factory-direct supply, we ensure competitive pricing and the flexibility for wholesale orders, making it an ideal choice for bulk purchases. The switch's compact size and variety of colors allow for easy integration into a wide range of applications, from electrical devices to automotive systems.
What Are the Key Features of Our Switch?
Key features include a maximum current of 10(3)A, a maximum voltage of 250V AC, and a mechanical life of 50,000 cycles. It also boasts excellent electrical properties with a contact resistance of ≤50mΩ and an insulation resistance of ≥1000MΩ. The dielectric strength of 1500VAC for 1 minute ensures safety under high voltage conditions.
How Does Our Switch Compare to Others on the Market?
Our switch offers superior durability and reliability, with a longer mechanical and electronic life compared to many competitors. The variety of colors and compact dimensions make it highly versatile. Additionally, our factory-direct supply and wholesale pricing provide unbeatable value for money.
