Description
Our rocker switches feature a contact resistance of ≤50mΩ, an insulation resistance of ≥1000MΩ, and a dielectric strength of 1500V AC for 1 minute. They are rated for an operating temperature range of T55, T85, and T125, ensuring they can withstand harsh environments. With a mechanical life of 100,000 cycles and an electrical life of 10,000 cycles, these switches offer exceptional longevity.
One of the standout features of our rocker switches is the built-in LED illumination, which provides clear visual indication of the switch’s status. The switches are also IP54 rated, offering protection against dust and water splashes.
We offer wholesale pricing and bulk order discounts, making it easy for you to stock up on these essential components. Our switches are CQC, CE, ENEC, and UL certified, ensuring they meet the highest safety standards. Choose us as your supplier for reliable, high-quality rocker switches.
|
contact resistance
|
≤50MΩ
|
electronic life
|
10000
|
|
insulation resistance
|
≥1000MΩ
|
operating temperature
|
T55 T85 T125
|
|
dielectric strength
|
1500V
|
IP code
|
IP54
|
Why Choose Our LED Rocker Switch?
Our LED Rocker Switch stands out with its built-in LED illumination, providing clear visual indication of the switch's status. This feature enhances user experience and safety, especially in low-light environments.
What Are the Key Specifications?
The switch is rated for 16A 125V, with an operating temperature range of T55, T85, and T125. It has a mechanical life of 100,000 cycles and an electrical life of 10,000 cycles, ensuring long-lasting performance.
Where Can It Be Used?
Our LED Rocker Switch is suitable for a wide range of applications, including cars, industrial equipment, marine vessels, buses, electric equipment, and off-road vehicles. Its IP54 rating offers protection against dust and water splashes, making it ideal for harsh environments.
