Description
Product Specifications:
– Max. Rating Current & Voltage (Resistive Load): 3A/250V AC
– Contact Resistance: ≤50mΩ
– Insulation Resistance: ≥1000 MΩ
– Dielectric Strength: 1500V
– Electronic Life (cycles): 10000
– Mechanical Life (cycles): 50000
– Operating Temperature: -25°C to +85°C
– IP Code: IP65
– Material: High-quality plastic
– Structure: Mechanical
– Head Type: Round Head
– Terminal Type: Pin terminal
– Mounting Hole Size: 16mm
– Terminal: 2 pin
– Color: Red
– Operation Type: Momentary
– Certificate: CQC CE
Product Advantages:
Our foot switch stands out from the competition with its IP65 waterproof rating, ensuring durability in wet environments. The mechanical structure guarantees reliable performance, and the long electronic and mechanical life cycles mean fewer replacements and lower costs over time. As a factory supplier, we offer competitive wholesale prices and the flexibility to customize switches to meet your specific requirements.
Applications:
Ideal for home appliances, industrial machinery, and any application requiring a momentary foot switch. Its compact size and robust design make it suitable for a wide range of uses.
After-Sales Service:
We provide comprehensive after-sales service, including technical support and warranty coverage. Our dedicated team is always ready to assist you with any questions or concerns.
Contact us today to take advantage of our factory direct wholesale prices and experience the quality and reliability of our products.
| Max.Rating Current & Voltage(Resistive Load) | 3A/250V AC |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥1000 MΩ |
| Dielectric Strength | 1500V |
| Electronic Life(cycles) | 10000 |
| Mechanical Life(cycles) | 50000 |
| Operating temperature | -25°c~+85°c |
| IP code | IP65 |
Why Choose Our 16mm Momentary Waterproof Foot Switch?
Our foot switch is designed with durability and reliability in mind. The IP65 waterproof rating ensures it can withstand wet environments, making it ideal for various applications. The mechanical structure guarantees consistent performance, and the long life cycles mean fewer replacements and lower costs.
What Are the Key Features of Our Foot Switch?
Key features include a 16mm mounting hole size, 3A/250V AC rating, and a compact, round head design. The pin terminal type and 2-pin configuration make it easy to install and use. Additionally, our product is customizable to meet your specific needs.
How Can We Benefit Your Business?
As a factory supplier, we offer competitive wholesale prices and the flexibility to customize switches. Our dedicated after-sales service ensures you have the support you need. Choose us for quality, reliability, and value.
