Factory Wholesale 16mm Push Button Switch – Top Quality Supplier
Introducing our high-quality 16mm push button switch, available directly from our factory. As a leading supplier, we offer competitive wholesale prices without compromising on quality. This switch is designed for durability and reliability, making it an ideal choice for various applications.
Product Specifications:
- Max. Current: 3A
- Max. Voltage: 250V AC
- Place of Origin: Shanghai, China
- Brand Name: Shining Key (SK)
- Model Number: AD16
- LED Indicator: Yes, with voltages of 2V, 6V, 12V, 24V, 110V, 220V
- Switch Combination: 1NO1NC, 2NO2NC
- Pushbutton Head: Round, mushroom, square, rectangular
- Panel Cutout: 16mm
- Operating Temperature: -5℃ to +75℃
- Action: Alternate, moment
- Electrical Life: 50,000 times
- Certification: CQC, CE
- Protection Level: IP40
- Size: 16mm
- Rated Voltage: 240V
Product Advantages:
- High Quality: Our switches are manufactured with precision and undergo strict quality control to ensure long-lasting performance.
- Versatile: Suitable for a wide range of applications, including industrial machinery, control panels, and more.
- Customizable: Choose from various pushbutton head shapes and LED indicator voltages to meet your specific needs.
- Reliable: With a high electrical and mechanical life, our switches are built to withstand heavy use.
After-Sales Service:
We are committed to providing excellent customer service. If you have any questions or concerns, our dedicated support team is here to assist you.
Why Choose Us?
- We are a factory direct supplier, offering wholesale prices.
- Our products are certified by CQC and CE, ensuring safety and compliance.
- We provide customization options to meet your unique requirements.
| Max. Rating Current & Voltage (Resistive Load) |
3A 250V AC indicator light |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥100MΩ 220 volt led indicator lights |
| Dielectric Resistance | 1,500V |
| Electronic life(cycles) | Momentary:50,000 Alternate:25,000 |
| Mechanical life(cycles) | Momentary:200,000 Alternate:50,000 |
| Certification |
CQC , CE |
| Operating temperature | -5℃~+75℃ |
| IP code | IP40 |
Why Choose Our 16mm Push Button Switch?
Our 16mm push button switch stands out for its durability, versatility, and high-quality construction. As a factory direct supplier, we offer competitive wholesale prices without compromising on quality. With CQC and CE certifications, you can trust that our switches meet the highest safety and performance standards.
What Are the Key Features?
Key features include a 3A 250V AC rating, customizable switch combinations (1NO1NC, 2NO2NC), and a long electrical life of 50,000 times. The switch also comes with an LED indicator, available in various voltages, making it suitable for a wide range of applications.
How Can We Help You?
We understand that every customer has unique needs. That's why we offer customization options to tailor the switch to your specific requirements. Our dedicated support team is also available to assist you with any questions or concerns you may have.
