Description
|
contact resistance
|
≤50MΩ
|
electronic life（cycles）
|
alternate：25000
|
|
insulation resistance
|
≥100MΩ
|
mechanical life（cycles）
|
alternate：50000
|
|
dielectric strength
|
1500V
|
operating temperature
|
5T75
|
|
IP code
|
IP40
|
max.rating current & voltage
|
3A 250V AC
|
Why Choose Our 16mm Push Button Switch?
Our 16mm Push Button Switch stands out for its durability, reliability, and versatility. With a factory-direct supply, we ensure competitive pricing and high-quality standards. The 1NO1NC configuration allows for flexible usage in various electrical systems, while the red LED provides clear visual indication. The switch's high mechanical and electrical life ensure long-term reliability, making it ideal for industrial machinery, home appliances, and automotive applications.
What Are the Key Features of Our Switch?
Key features include a contact resistance of ≤50mΩ, a dielectric strength of 1500V, and an operating temperature range of -5°C to 75°C. The IP40 protection level ensures durability in standard environments, and the switch is rated for 3A at 250V AC. The built-in 12V red LED adds to its functionality, providing clear status indication.
How Does Our Switch Compare to Others on the Market?
Our switch offers superior quality and value compared to similar products on the market. With a factory-direct supply, we eliminate middleman costs, passing the savings on to you. The high mechanical and electrical life, combined with a durable plastic construction and clear red LED indication, set our switch apart from the competition. Choose our switch for quality, reliability, and cost-effectiveness.
