Description
| Max. Rating Current & Voltage |
1A 250V AC |
| Contact Resistance | ≤50mΩ plastic push button switch |
| Insulation Resistance | 100MΩ |
| Dielectric Resistance | 1,500V mechanical momentary push button switch |
| Electronic life(cycles) | Momentary:10,000 Alternate:5,000 |
| Mechanical life(cycles) | Momentary:50,000 Alternate:10,000 |
| Certification |
CQC , CE |
| Operating temperature | -25℃~+55℃ |
| IP code | IP40 miniature push button switch |
Why Choose Our 16MM Round Momentary/Locking Panel Mount Switch?
Our switch stands out due to its high-quality construction, reliable performance, and customizable options. As a factory supplier, we offer competitive pricing and bulk order discounts, making it an ideal choice for businesses looking for cost-effective solutions.
What Are the Key Features of Our Switch?
Key features include a 1A 250V AC rating, ≤50mΩ contact resistance, 100MΩ insulation resistance, and 1,500V dielectric resistance. It also offers both momentary and alternate electronic life cycles, ensuring long-lasting durability. Certified by CQC and CE, it meets international quality standards.
What Are the Applications of Our Switch?
Our switch is suitable for a wide range of applications, including industrial control, home appliances, electronic devices, and automotive applications. Its compact size and reliable performance make it a versatile choice for various industries.
