Description
Product Specifications:
- Size: 19mm/22mm
- Material: Stainless Steel, Nickel-plated Brass, or Gold-Plated Brass
- LED: Integrated LED ring light
- IP Rating: IP67
- Switch Rating: 2A/36VAC
- Mechanical Life: >1,000,000 times
- Electrical Life: >200,000 times
- Operating Temperature: -20°C to +55°C
Key Features:
- Waterproof Design: With an IP67 rating, this switch is perfect for outdoor or wet environments.
- Durable Construction: Made from high-quality stainless steel and brass, ensuring long-lasting performance.
- LED Ring Light: Provides clear indication and enhances visibility in low-light conditions.
- Factory Direct Pricing: As a factory, we offer competitive wholesale prices without compromising on quality.
Our push button switch is suitable for various applications, including industrial machinery, automotive controls, and more. We provide excellent after-sales service and support to ensure your satisfaction. Contact us today for wholesale inquiries and more information!
| Panel Thickness | 1-10mm |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥1000 MΩ manufacture push button switch |
| Torque | 5-14Nm |
| Operating Pressure | About 4N |
| Operating Stroke | About 1.8mm |
| Mounting Hole Size | 22mm mini waterproof push button switch |
| Dielectric Strength | 2000VAC mechanical push button switch |
| Electronic Life | >1,000,000 times |
| Mechanical Life | >200,000 times |
| Operating temperature | -20°c~+55°c |
| IP code | IP67 IK09 |
| Switch Rating | 2A /36VAC |
| Contact Configuration | 1NO |
| Operating Type | Momentary |
| The Front Shape | High Round |
| The Crust Material | Stainless Stell,Nickel-plated Brass or Gold-Plated Brass |
|
Material |
Contact : Sliver Alloy (Can be made to order) |
Why Choose Our 19mm/22mm LED Ring Light Stainless Steel Waterproof Push Button Switch?
Our push button switch stands out due to its waterproof design, durable construction, and integrated LED ring light. It is perfect for applications in wet or outdoor environments, ensuring reliable performance even under harsh conditions. The stainless steel and brass materials used guarantee longevity and resistance to corrosion.
What Are the Key Features of This Switch?
Key features include an IP67 waterproof rating, a mechanical life of over 1,000,000 times, and an electrical life of over 200,000 times. The LED ring light provides clear indication, making it easy to locate and operate the switch in low-light conditions. Additionally, our factory direct pricing ensures you get the best value for your money.
What Applications Is This Switch Suitable For?
This switch is suitable for a wide range of applications, including industrial machinery, automotive controls, outdoor equipment, and more. Its durability and waterproof design make it an ideal choice for any environment where reliability and performance are crucial.
