Description
Key specifications include a maximum current of 5A, maximum voltage of 250V, and a contact resistance of ≤50mΩ. It operates within a temperature range of -20℃ to +55℃, ensuring versatility in various climates. The switch also features a mechanical life of over 1,000,000 times and an electrical life of over 200,000 times, providing exceptional durability.
What sets our product apart is its customizable options. Choose from different front shapes (Domed Flat, High Round), terminal types, and switch combinations (1NO1NC, 1NO, 2NO2NC, 2NO, 1NC) to suit your specific needs. The contact material is made of high-quality Silver Alloy, ensuring excellent conductivity.
As a factory supplier, we offer competitive pricing and flexible order quantities. Whether you’re looking to buy in bulk or need a custom solution, we’ve got you covered. Our dedicated customer service team is always ready to assist with any inquiries or support you may need.
| Panel Thickness | 1-10mm |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥1000 MΩ 4 pin push button switch |
| Torque | 5-14Nm |
| Operating Pressure | About 4N |
| Operating Stroke | About 1.8mm |
| Mounting Hole Size | 22mm |
| Dielectric Strength | 2000VAC |
| Electronic Life | >1,000,000 times |
| Mechanical Life | >200,000 times |
| Operating temperature | -20°c~+55°c |
| IP code | IP67 IK09 |
| Switch Rating | 2A /36VAC emergency push button switch |
| Contact Configuration | 1NO |
| Operating Type | Momentary elevator push button switch |
| The Front Shape | High Round |
| The Crust Material | Stainless Stell,Nickel-plated Brass or Gold-Plated Brass |
|
Material |
Contact : Sliver Alloy (Can be made to order) |
Why Choose Our 19mm IP67 Waterproof Metal Push Button Switch?
Our switch is designed to withstand harsh environments with its IP67 waterproof and dustproof rating, ensuring reliable operation in outdoor or industrial settings. The stainless steel construction and high-quality Silver Alloy contacts provide exceptional durability and conductivity.
What Makes Our Product Stand Out?
Unlike other switches on the market, ours offers customizable options such as different front shapes, terminal types, and switch combinations. This flexibility allows you to tailor the switch to your specific application needs, ensuring optimal performance and compatibility.
Can I Buy in Bulk or Get a Custom Solution?
Absolutely! As a factory supplier, we offer competitive pricing for bulk orders and can provide custom solutions to meet your unique requirements. Our dedicated customer service team is always available to assist with any inquiries or support you may need.
