Description
Product Specifications:
– Material: Contacts made of brass with tin plating, and housing made of PA66, UL94V-0 for enhanced safety and longevity.
– Dimensions & Poles: Available in 3.00/3.08/5.00/5.08/7.62mm dimensions with 2-4 poles, catering to diverse connection needs.
– Electrical: Rated at 300V and 16A (note: corrected from 12A in attributes for consistency with table), with low contact resistance of 20mΩ and high insulation resistance of >5000MΩ at DC500V.
– Environmental: Operates efficiently from -40°C to 150°C, with short-time temperature resistance up to +250°C for 5 seconds.
– Certifications: CCC, CQC, CE, RoHS, ENEC, KEMA certified, ensuring compliance with global standards.
Product Advantages:
Our terminal blocks stand out with their superior material quality, precise dimensions, and robust electrical performance. The pluggable design allows for easy installation and maintenance, reducing downtime and increasing productivity. Additionally, our factory direct supply ensures competitive pricing and reliable availability.
Applications:
Ideal for use in industrial automation, control panels, power distribution systems, and any application requiring secure and reliable electrical connections.
After-Sales Service:
We offer comprehensive after-sales support, including technical assistance, warranty services, and customization options to meet your specific requirements. As a trusted supplier, we are committed to your satisfaction and success.
| Material | |
| Contact | Brass, Tin Plated |
| Housing | PA66 ,UL94V-0 |
| Color | Green 10 pin connectors |
| Environmental | |
| Operating temperature | -40°C ~ 150°C |
| Short-time temperature | +250°C for 5 sec |
| Electrical | |
| Rated voltage | 300V |
| Rated current | 16A screw clamp wire connectors |
| Contact resistance | 20mΩ |
| Insulation resistance | >5000MΩ DC500V |
| Withstanding voltage | AC2000V/Min terminal connectors |
Why Choose Our PCB Pluggable Terminal Blocks?
Our PCB pluggable terminal blocks offer unmatched quality, durability, and performance. With a pluggable design, they simplify installation and maintenance, reducing downtime. The superior material quality ensures long-lasting reliability, even in harsh environments.
Key Features for Your Benefit
Featuring 2 to 4 poles and a 5mm pitch, our terminal blocks cater to a wide range of connection needs. The high insulation resistance and low contact resistance guarantee efficient and safe electrical connections. Additionally, our factory direct supply ensures competitive pricing and reliable availability.
Ideal for Industrial Applications
Whether you're working on industrial automation, control panels, or power distribution systems, our terminal blocks provide the secure and reliable connections you need. With comprehensive after-sales support, you can trust us to be your partner in success.
