Factory Wholesale 2-Pin 10mm Round Screwed Push Button Switch for Appliances

100 - 1,999  pieces
$0.28

2,000 - 4,999  pieces
$0.25

>= 5,000  pieces
$0.22

0 reviews

Factory Wholesale 2-Pin Push Button Switch – Reliable for Appliances

Description

Our 2-Pin 10mm Round Screwed Push Button Switch is a top-quality electronic switch designed specifically for appliances. As a factory supplier, we offer wholesale prices and ensure direct delivery from our manufacturing facility. This switch boasts a durable plastic structure with both electronic and mechanical components, making it reliable and long-lasting. It features a maximum current of 1A and a maximum voltage of 250V AC, suitable for a wide range of applications including electric, home appliances, and industrial control. With an electronic life of 10,000 cycles, it outperforms many competitors in terms of durability. The switch also offers excellent insulation resistance (≥100mΩ) and dielectric strength (1500V), ensuring safety and reliability. Its IP40 rating provides protection against solid objects larger than 1mm. Our switch stands out with its round head design and pin terminals, offering ease of installation and use. As a factory supplier, we provide competitive pricing, fast delivery, and excellent customer service. Choose our switch for your appliance needs and experience the difference in quality and performance.
contact resistance
≤50MΩ
electronic life(cycles)
10000
insulation resistance
≥100MΩ
operating temperature
-5℃ to +55℃
dielectric strength
1500V
IP code
IP40

Electronic component device for cross-border e-commerceElectronic gadget product for cross-border e-commerce


Key Features

Our 2-Pin 10mm Round Screwed Push Button Switch is designed for durability and reliability. With a plastic structure and both electronic and mechanical components, it offers a long electronic life of 10,000 cycles, ensuring long-lasting performance.

Superior Specifications

This switch supports a maximum current of 1A and a maximum voltage of 250V AC, making it suitable for a variety of applications. Its excellent insulation resistance (≥100mΩ) and dielectric strength (1500V) ensure safety and reliability in any environment.

Why Choose Us?

As a factory supplier, we offer competitive wholesale prices, fast delivery, and exceptional customer service. Our switch's IP40 rating and round head design with pin terminals make it easy to install and use. Choose our switch for your appliance needs and experience the difference in quality and performance.

Push Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch Customized

Additional information

Max. Current

1A

Max. Voltage

250V AC

Place of Origin

Shanghai, China

Brand Name

Yongxing

Model Number

KA1B-11

LED

NO

Application

Electric, Home Appliance, Industrial Control, latching

Material

plastic

Structure

Electronic, Mechanical, Electromagnetic

Head Type

Round Head

Terminal Type

Pin terminal

Whether the smart

NO

illuminated Type

none

IP level

IP40

Switch Combination

1NO1NC

Electronic life(cycles)

10,000

Contact Resistance

≤50mΩ

Insulation Resistance

≥100mΩ

IP code

IP40

Dielectronic Strength

1500V

Operating temperature

-5℃~+55℃
