Description
Product Specifications:
– Max. Current: 6A
– Max. Voltage: 250V
– Place of Origin: Shanghai, China
– Brand Name: Shangkai (SK)
– Model Number: KCD7-11-CF1B-P-P-110
– Mechanical Life: 100,000 cycles
– Certificate: CQC CE
– Function: SPST
– Color: Grey
– Housing Material: PA66
Product Advantages:
– High contact resistance (<50mΩ) and insulation resistance (>1000MΩ) ensure safety and reliability.
– Dielectric strength of 1500VAC for 1 minute guarantees durability under extreme conditions.
– Wide operating temperature range (T55) makes it suitable for various environments.
– Long electronic life of 10,000 cycles.
Differentiated Competitiveness:
Our factory’s commitment to quality and customization sets us apart from competitors. We offer competitive wholesale prices and free samples, making it easy for you to test and trust our products.
After-Sales Service:
We provide comprehensive after-sales support, including technical assistance and warranty services, ensuring your satisfaction with every purchase.
| contact resistance | <50m |
| insulation resistance | >1000MΩ |
| dielectric strength | 1500vac,1min |
| operating temperature | t55 |
| electronic life | 10000 |
| max.rating current&voltage |
6a 250vac |
Why Choose Our 2 Pin Rocker Switch?
Our 2 Pin Rocker Switch is designed for reliability and durability, making it an ideal choice for electrical control and appliance switching. With a high contact resistance and insulation resistance, it ensures safety and longevity in your applications.
What Makes Our Product Stand Out?
Our factory's advanced production facilities and strict quality control measures result in a switch that outperforms competitors. We offer customization options and competitive wholesale prices, making it easy for you to get the exact product you need.
How Can We Support Your Business?
As a direct factory supplier, we provide not only high-quality products but also excellent after-sales service. Our technical support team is always ready to assist you, ensuring a smooth and hassle-free experience with our products.
