Description
|
item
|
value
|
|
Place of Origin
|
Shanghai,China
|
|
Brand Name
|
Sk(shangkai) yongxing
|
|
Model Number
|
LA133-A1.MD-K11 R
|
|
Protection Level
|
IP40 IP65 IP67
|
|
Max. Current
|
10A
|
|
Max. Voltage
|
660 VAC
|
|
Rated Insulation Voltage
|
660v ac
|
|
Rated Thermal Current
|
10A
|
|
Max.insulation voltage
|
2500 V/min
|
|
Usage Category
|
AC-15 DC-13
|
|
Mechanical Life
|
1000,000
|
|
Operation frequency
|
1200 cycles/h
|
|
Electrical life for AC-15
|
600000 cycles
|
|
Electrical life for DC-13
|
250000 cycles
|
|
Mounting Hole Size
|
22mm Diameter
|
|
Lamp Voltage
|
6v 12v 24v 36v 48v 110v 220v 380v
|
Why Choose Our Push Button Switch?
Our 22mm 1NO Latching Push Button Switch stands out for its exceptional quality, durability, and versatility. With a factory-direct supply, we ensure competitive pricing and reliable delivery. The switch's high current and voltage ratings, along with its robust protection levels, make it ideal for demanding industrial environments. Its long mechanical and electrical lives guarantee extended use without frequent replacements, saving you time and money.
Key Features and Benefits
The switch's latching action provides a stable on/off state, essential for continuous operation in machinery and lighting systems. Its support for multiple lamp voltages allows for flexible integration into various setups. Additionally, our commitment to quality and after-sales service ensures that you receive a product that meets your expectations and performs reliably over time.
Applications and Suitability
This push button switch is perfect for industrial control, machinery operation, lighting systems, and automation applications. Its compact size and high performance make it a versatile choice for a wide range of industries. Whether you're looking to upgrade your existing equipment or design a new system, our switch offers the reliability and functionality you need.
