Description
|
item
|
value
|
|
Place of Origin
|
Shanghai,China
|
|
Brand Name
|
Sk(shangkai) yongxing
|
|
Model Number
|
LA133-E1.X2S-K11
|
|
Protection Level
|
IP40 IP65 IP67
|
|
Max. Current
|
10A
|
|
Max. Voltage
|
660 VAC
|
|
Rated Insulation Voltage
|
660v ac
|
|
Rated Thermal Current
|
10A
|
|
Max.insulation voltage
|
2500 V/min
|
|
Usage Category
|
AC-15 DC-13
|
|
Mechanical Life
|
1000,000
|
|
Operation frequency
|
1200 cycles/h
|
|
Electrical life for AC-15
|
600000 cycles
|
|
Electrical life for DC-13
|
250000 cycles
|
|
Mounting Hole Size
|
22mm Diameter
|
Why Choose Our 22mm 1NO1NC Industrial Push Button Switch?
Our switch is designed for industrial use, offering robust construction and high-quality materials that ensure durability and longevity. With a 22mm diameter and 1NO1NC configuration, it is compatible with a wide range of industrial panels and electrical systems.
What Are the Key Features of Our Switch?
Our switch boasts a maximum current of 10A and voltage of 660 VAC, making it suitable for demanding industrial applications. It is rated for IP40, IP65, and IP67 protection levels, providing excellent resistance to dust and water ingress. Additionally, it has a long mechanical life of 1,000,000 cycles and a high electrical life, ensuring reliable performance over time.
How Does Our Switch Compare to Others on the Market?
Our switch stands out from the competition with its factory-direct pricing, ensuring you get the best value for your money. We are a leading supplier, offering wholesale prices and excellent customer service. Choose our switch for unbeatable quality, performance, and support.
