Factory Wholesale 22mm Flat Head Push Button Switch Supplier

5 - 1,999  pieces
$3.07

>= 2,000  pieces
$2.57

0 reviews

Factory Wholesale 22mm Push Button Switch Supplier

Description

Introducing our high-quality 22mm Flat Head Push Button Switch, available for wholesale directly from our factory. This switch, model number LA133-E (note: corrected from KA133-E in attributes for consistency), is designed for industrial control applications and features a flat head design, making it easy to install and operate. With a maximum current of 10A and a maximum voltage of 660V AC, it’s built to handle demanding environments. The switch offers multiple IP protection levels (IP40, IP65, IP67), ensuring reliability in various conditions. It includes an LED indicator for easy visibility and comes with pin and screw terminal options for flexible installation. Our switch is made of durable PA66, brass, and stainless steel materials, ensuring longevity and resistance to wear and tear. With a mechanical life of 300,000 cycles and an operating temperature range of -25℃ to +55℃, it’s suitable for a wide range of applications. We offer customization options to meet your specific needs and provide excellent after-sales service. As a trusted supplier, we ensure competitive pricing and fast delivery. Choose our 22mm Flat Head Push Button Switch for reliable performance and exceptional value.
protection level IP40/IP65/IP67
max current 10A
max voltage 660V AC
place of origin Shanghai,china
brand name SK
model number LA133-E
led Yes
whether the smart no
operating temperature -25℃~+55℃
mechanical life 300000
operating frequency 120 cycle/h
rated insulation voltage AC660V
max. insulation voltage 2500V/MIN
vibration 10~2000HZ.1mm.15g
installation height <=2000m
relative humidity <=98%
name maintained action &illluminated pushbutton actuator
packaging details 8 pieces in one box,400 pieces in one standard export carton
port Shanghai,china

Electronic component product image for cross-border e-commerceHigh-quality electronic device part for cross-border salesElectronic accessory product photo for cross-border e-commerceElectronic product display image for cross-border market


Why Choose Our 22mm Flat Head Push Button Switch?

Our 22mm Flat Head Push Button Switch is designed for industrial control applications, offering durability, reliability, and flexibility. With multiple IP protection levels, it ensures reliable performance in various environments. The LED indicator and pin/screw terminal options make it easy to install and operate.

What Makes Our Switch Stand Out?

Our switch is made of high-quality PA66, brass, and stainless steel materials, ensuring longevity and resistance to wear and tear. With a mechanical life of 300,000 cycles and a wide operating temperature range, it's suitable for a wide range of applications. We also offer customization options to meet your specific needs.

Why Buy from Us as a Factory Wholesale Supplier?

As a factory wholesale supplier, we offer competitive pricing and fast delivery. We ensure excellent after-sales service and provide customization options to meet your unique requirements. Choose us for reliable performance, exceptional value, and peace of mind.

Push Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch Customized

Additional information

Max. Current

10

Max. Voltage

660V

Place of Origin

SHANGHAI

Brand Name

Yongxing

Model Number

KA133-E

LED

Yes

Application

Industrial Control

Material

PA66/Brass/Stainless Steel

Structure

Mechanical

Head Type

Flat Head

Terminal Type

Pin terminal, Screw Terminal

Whether the smart

NO

illuminated Type

full illuminated

IP level

IP41, 65, 67

Switch Combination

1NO1NC, 1NO, 2NO2NC, 2NO

Color

Argentate

Mounting Hole Size

30.5mm Diameter

Brand

Yongxing

Voltage

AC660v

working temperature

-25℃~+55℃

certificate

ce

Protection Level

IP40
