Description
| Panel Thickness | 1-10mm |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥1000 MΩ 4 pin push button switch |
| Torque | 5-14Nm |
| Operating Pressure | About 4N |
| Operating Stroke | About 1.8mm |
| Mounting Hole Size | 22mm |
| Dielectric Strength | 2000VAC |
| Electronic Life | >1,000,000 times |
| Mechanical Life | >200,000 times |
| Operating temperature | -20°c~+55°c |
| IP code | IP67 IK09 |
| Switch Rating | 2A /36VAC emergency push button switch |
| Contact Configuration | 1NO |
| Operating Type | Momentary elevator push button switch |
| The Front Shape | High Round |
| The Crust Material | Stainless Stell,Nickel-plated Brass or Gold-Plated Brass |
|
Material |
Contact : Sliver Alloy (Can be made to order) |
Why Choose Our 22mm IP67 Waterproof Metal Push Button Switch?
Our switch stands out with its robust construction, ensuring longevity and reliability in industrial settings. The IP67 rating guarantees protection against water and dust, making it suitable for harsh environments. With customizable options and competitive wholesale prices, we offer a cost-effective solution for your push button switch needs.
What Are the Key Features of Our Switch?
Key features include a contact resistance of ≤50mΩ, insulation resistance of ≥1000 MΩ, and a high mechanical life of >1,000,000 times. It also offers a wide operating temperature range and a variety of crust materials to choose from.
How Can We Help You with Customization?
As a factory and supplier, we have the capability to customize the switch to meet your specific requirements. Whether it's a different size, material, or contact configuration, we can tailor the switch to fit your application perfectly. Contact us today to discuss your customization needs.
