Description
Product Specifications:
- Max. Current: 1A
- Max. Voltage: 250VAC
- Size: 16MM
- Operating Temperature: -25℃~+55℃
- IP Level: IP40
- Electronic Life (cycles): Moment: 10,000, Alternate: 5,000
- Mechanical Life (cycles): Moment: 50,000, Alternate: 100,000
- Contact Resistance: ≤50mΩ
- Insulation Resistance: ≥100MΩ
- Dielectric Strength: 1,500V
- Certification: CQC, CE
- LED: Yes
- Color: Customizable
Product Advantages:
- Durable and reliable with a long mechanical and electronic life.
- Customizable color options to meet your specific needs.
- High insulation and dielectric strength for enhanced safety.
- Factory direct supply, ensuring competitive pricing and quality control.
Applications:
This push button switch is widely used in various electronic devices, control panels, and industrial equipment.
After-sales Service:
We offer comprehensive after-sales service, including technical support and warranty coverage, to ensure your satisfaction.
| Contact resistance | ≤50mΩ |
| Insulation resistance | ≥100MΩ |
| Dielectric strength | 1500v |
| Electronic life (cycles) | Moment:10000 Alternate:5000 |
| Mechanical life (cycles) | Moment:50000 Alternate:100000 |
| Operating temperature | 25T55 |
| IP code | IP40 |
| Max.Rating Current&Voltage | 1A/250V AC |
| Certification | CQC, CE |
Why Choose Our Momentary Push Button Switch?
Our Momentary Push Button Switch stands out due to its durability, reliability, and customizable options. With a long mechanical and electronic life, it ensures stable performance in various applications. The customizable color allows you to match it with your device's design, enhancing its aesthetic appeal.
What Are the Key Specifications?
Key specifications include a maximum current of 1A, a maximum voltage of 250VAC, a 16MM size, and an IP40 protection level. It also features an LED indicator, high insulation and dielectric strength, and certifications like CQC and CE.
How Can We Assist You?
As a factory supplier, we offer competitive pricing, quality control, and comprehensive after-sales service. Whether you need technical support or warranty coverage, we are here to assist you. Contact us today to learn more about our products and services.
