Description
| Contact Resistance:≤50mΩ | Insulation Resistance:≥100mΩ |
| Dielectric Strength:1,500V,1min | Electronic Life:25,000 cycles |
| Operating temperature:-25℃-55℃ | Rating current/voltage:3A/250V AC |
Why Choose Our 3 Position 220V Rotary Switch?
Our 3 position 220V rotary switch stands out for its high quality, durability, and customization options. As a factory direct supplier, we offer competitive wholesale pricing without compromising on quality. The switch's 16mm mounting hole size makes it versatile for various applications, while its 3A/250V AC rating ensures reliable performance in demanding electrical environments.
What Are the Key Features of Our Rotary Switch?
Key features include a contact resistance of ≤50mΩ, insulation resistance of ≥100MΩ, and dielectric strength of 1,500V for 1 minute. With an electronic life of 25,000 cycles and a mechanical life of 50,000 cycles, our switch offers long-lasting reliability. The wide operating temperature range of -25℃ to 55℃ makes it suitable for use in various climates.
Can We Customize the Rotary Switch to Meet Our Needs?
Absolutely! We understand that different applications may require specific customizations. When ordering in sufficient quantities, we can tailor the switch to meet your unique requirements, ensuring it perfectly fits your needs.
