Description
Premium Quality 3A 250V 12mm 2NO 2NC LED Push Button Switch – Factory Direct Wholesale
Discover our high-quality 12mm 2NO 2NC LED push button switch, designed to meet your industrial and commercial needs. As a leading factory and supplier, we offer competitive wholesale prices and customization options to suit your specific requirements. Our switch boasts a 3A/250V AC rating, ensuring reliable performance in various applications. With a self-locking operation type and white LED lamp color, it provides clear visual indication and ease of use. The switch is made with durable materials, ensuring a long mechanical life of 50,000 cycles and an electrical life of 25,000 cycles. Our factory, equipped with advanced experimental equipment and a 5S management system, guarantees top-notch quality and consistency. We have over 60 senior engineers dedicated to innovation and excellence. Choose us for your push button switch needs and experience the difference in quality and service.
Key Features:
- Max. Rating Current & Voltage: 3A/250V AC
- Contact Resistance: ≤50mΩ
- Insulation Resistance: ≥1000 MΩ
- Dielectric Strength: 1500V
- Mechanical Life: 50,000 cycles
- Electrical Life: 25,000 cycles
- Operating Temperature: -5°C to +75°C
- IP Code: IP40
Why Choose Us?
We are a factory direct supplier, offering competitive wholesale prices and customization services. Our switches are CE, CQC, and ROHS certified, ensuring compliance with international standards. With a focus on quality and customer satisfaction, we strive to exceed your expectations. Contact us today to discuss your needs and place your order.
| Max.Rating Current & Voltage(Resistive Load) | 3A/250V AC |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥1000 MΩ |
| Dielectric Strength | 1500V |
| Electronic Life(cycles) | 25000 |
| Mechanical Life(cycles) | 50000 |
| Operating temperature | -5°c~+75°c |
| IP code | IP40 |
Why Choose Our Push Button Switch?
Our push button switch stands out for its high quality, durability, and customization options. With a 3A/250V AC rating and a long mechanical life of 50,000 cycles, it ensures reliable performance in various industrial and commercial applications. The self-locking operation type and white LED lamp color provide clear visual indication and ease of use.
What Makes Us Different?
As a factory direct supplier, we offer competitive wholesale prices and customization services to meet your specific requirements. Our factory is equipped with advanced experimental equipment and a 5S management system, ensuring top-notch quality and consistency. With over 60 senior engineers dedicated to innovation and excellence, we strive to exceed your expectations.
What Are the Key Features?
Key features include a 3A/250V AC rating, ≤50mΩ contact resistance, ≥1000 MΩ insulation resistance, 1500V dielectric strength, and an IP40 protection level. The switch also boasts a long mechanical life of 50,000 cycles and an electrical life of 25,000 cycles, ensuring reliable performance over time.
