Description
Key Features:
– **Material**: PA66, known for its strength and resistance to heat and chemicals.
– **Max. Current**: 16A, providing ample power for most devices.
– **Max. Voltage**: 250V AC, suitable for a wide range of electrical systems.
– **Mechanical Life**: 50,000 cycles, ensuring long-lasting reliability.
– **Contact Resistance**: ≤50mΩ, minimizing energy loss.
– **Insulation Resistance**: ≥1000MΩ, enhancing safety.
– **Dielectric Strength**: 1500VAC for 1 minute, ensuring electrical isolation.
– **Operating Temperature**: T85, suitable for high-temperature environments.
– **Certificate**: CQC, CE, ROHS compliant, meeting international standards.
– **Color Options**: Red, Yellow, Green, Black, Blue, Orange, White, Gray, to match your design needs.
As a factory supplier, we offer wholesale pricing and bulk discounts, making it an affordable choice for businesses. Our commitment to quality ensures that each switch is rigorously tested before shipping. Choose our 3Pin Rocker Switch for a reliable, durable, and cost-effective solution.
|
item
|
value
|
|
Place of Origin
|
Shanghai, China
|
|
Brand Name
|
SK(shangkai) Yongxing
|
|
Model Number
|
KCD1
|
|
Max. Current
|
16A
|
|
Max. Voltage
|
250V AC
|
|
Mechanical Life
|
50000 Cycles
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥1000MΩ
|
|
Dielectric Strength
|
1500VAC 1 Minute
|
|
Operating Temperature
|
T85
|
|
Certificate
|
CQC CE ROHS
|
|
Circuit
|
SPST
|
|
Dimension Code
|
A1(27.6*10.6mm)
|
|
LED
|
24V
|
|
Color
|
Red,Yellow,Green,Black,Blue,Orange,White,Gray
|
|
Function
|
On Off
|
Why Choose Our 3Pin Rocker Switch?
Our 3Pin Rocker Switch stands out with its PA66 material, ensuring durability and resistance to harsh conditions. The on-off function and welding terminals make it easy to install and use. With a max current of 16A and max voltage of 250V AC, it's suitable for a wide range of applications.
What Are the Key Advantages?
Key advantages include a long mechanical life of 50,000 cycles, low contact resistance, and high insulation resistance. These features ensure reliable performance and safety. Additionally, our switch is CQC, CE, and ROHS compliant, meeting international standards.
Can I Get Wholesale Pricing?
Yes! As a factory supplier, we offer wholesale pricing and bulk discounts. This makes our 3Pin Rocker Switch an affordable choice for businesses looking to purchase in large quantities. Contact us today for a quote!
