Description
Our Factory Wholesale 6A 250VAC IP65 Red Button Rocker Switch is a top-notch electrical component designed for various applications. This switch, with a model number of KCD3-11-FB1B-B-B-01, is manufactured by SK(shangkai) Yongxing, a trusted brand from Shanghai, China. It boasts a maximum current rating of 6A and a maximum voltage rating of 250V AC, ensuring reliable performance in demanding environments. The switch features a mechanical life of 50,000 cycles and an electronic life of 10,000 cycles, demonstrating its durability and longevity. With a contact resistance of ≤50mΩ and an insulation resistance of ≥1000MΩ, it guarantees efficient and safe operation. The dielectric strength of 1500VAC for 1 minute further enhances its reliability. This rocker switch is not only waterproof with an IP65 rating but also available in multiple colors including red, yellow, green, black, blue, orange, white, and gray, allowing for customization to suit different needs. As a factory supplier, we offer wholesale prices, making it an excellent choice for bulk purchases. Whether you’re looking for a reliable switch for your industrial, marine, or other applications, our product stands out with its high quality, durability, and competitive pricing.
|
item
|
value
|
|
Place of Origin
|
Shanghai, China
|
|
Brand Name
|
SK(shangkai) Yongxing
|
|
Model Number
|
KCD3-11-FB1B-B-B-01
|
|
Current Rating
|
6A/10A
|
|
Voltage Rating
|
250V AC
|
|
Mechanical Life
|
50000 Cycles
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥1000MΩ
|
|
Dielectric Strength
|
1500VAC 1 Minute
|
|
Electronic Life (cycles)
|
10,000
|
|
Certificate
|
CB ENEC17 ROHS
|
|
Circuit
|
SPST
|
|
Dimension Code
|
B1 (21.4x15x15.2 , 19.3×13.2×12.9)
|
|
Contact Piece Code
|
B (8 length, 4.8×0.8 standard)
|
|
Actuator Color
|
Red,Yellow,Green,Black,Blue,Orange,White,Gray
|
|
Switch Function
|
On Off Waterproof IP65
|
Why Choose Our Rocker Switch?
Our Rocker Switch stands out with its high current and voltage ratings, ensuring reliable performance in various applications. Its IP65 waterproof rating makes it suitable for marine and industrial environments where moisture resistance is crucial.
What Are the Key Features?
The switch features a long mechanical and electronic life, low contact resistance, high insulation resistance, and strong dielectric strength. It also comes in multiple colors, allowing for customization to match your specific needs.
Why Buy from Us?
As a factory supplier, we offer wholesale prices, ensuring you get the best value for your money. Our products are of high quality, durable, and come with reliable after-sales service. Choose us for your electrical component needs and experience the difference.
