Description
Introducing our premium 6A Round Rocker Switch with a 220V Red Light, a bestseller directly from our factory. As a leading supplier, we offer this high-quality switch at wholesale prices, making it an excellent choice for bulk purchases. Our switch boasts a current rating of 6A and a voltage rating of 250V AC, ensuring reliable performance in various applications. With a mechanical life of 50,000 cycles and an electronic life of 10,000 cycles, it outlasts many competitors on the market. The switch is available in a range of colors including red, yellow, green, black, blue, orange, white, and gray, offering versatility in design. It is certified with CQC, CE, CB, ENEC17, and ROHS, guaranteeing safety and compliance. Our switch features a low contact resistance of ≤50mΩ and a high insulation resistance of ≥1000MΩ, ensuring efficient and safe operation. Additionally, it has a dielectric strength of 1500VAC for 1 minute, providing robust protection against electrical faults. The switch is designed for operating temperatures ranging from 0~55℃, 0~85℃, and 0~105℃, making it suitable for diverse environments. With an IP41 and IP65 rating, it offers protection against dust and water ingress. As a factory-direct supplier, we offer competitive pricing and excellent customer service, ensuring a seamless purchasing experience.
|
item
|
value
|
|
Place of Origin
|
Shanghai, China
|
|
Brand Name
|
SK(shangkai) Yongxing
|
|
Model Number
|
KCD8-11N-CB1A-B-R-01-AC220/right side slot (110207-038)
|
|
Current Rating
|
6A
|
|
Voltage Rating
|
250V AC
|
|
Mechanical Life
|
50000 Cycles
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥1000MΩ
|
|
Dielectric Strength
|
1500VAC 1 Minute
|
|
Electronic Life (cycles)
|
10,000
|
|
Certificate
|
CQC CE CB ENEC17 ROHS
|
|
Circuit
|
SPST
|
|
Dimension Code
|
B1
|
|
Contact Piece Code
|
A
|
|
Lamp voltage
|
6v/12v/24v/110v/220v
|
Key Features
Our 6A Round Rocker Switch with 220V Red Light stands out with its long mechanical life of 50,000 cycles and low contact resistance, ensuring reliable and efficient operation. The red light indicator provides clear visual feedback, making it ideal for various applications.
Why Choose Us?
As a factory-direct supplier, we offer wholesale pricing on our bestselling 6A Round Rocker Switch. With strict quality control and certifications like CQC, CE, CB, ENEC17, and ROHS, you can trust in the safety and performance of our product.
Applications
This switch is perfect for electrical appliances, industrial machinery, home automation systems, and lighting control. Its versatility and durability make it a top choice for both professional and DIY projects.
