Description
|
item
|
value
|
|
Place of Origin
|
Shanghai, China
|
|
Brand Name
|
SK(shangkai) Yongxing
|
|
Model Number
|
KCD1-11-CA5C-B-R-01
|
|
Current Rating
|
16A
|
|
Voltage Rating
|
250V AC
|
|
Mechanical Life
|
50,000 Cycles
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥1000MΩ
|
|
Dielectric Strength
|
1500VAC 1 Minute
|
|
Electronic Life (cycles)
|
10,000
|
|
Certificate
|
CQC CE CB ENEC17 ROHS
|
|
Circuit
|
SPST 2 pin rocker switch
|
|
Dimension Code
|
A5 28x11mm
|
|
Contact Piece Code
|
C 6.3X0.8X9.5mm standard
|
|
Lamp voltage
|
no lamp
|
Why Choose Our Rocker Switch?
Our Rocker Switch stands out with its CE certification, ensuring safety and compliance with international standards. The 16A 250VAC rating makes it suitable for a wide range of applications, from household appliances to industrial equipment. The SPST 2-pin configuration provides simple on-off control, while the illuminated red rocker adds a visual indicator for easy operation.
What Are the Key Features?
Key features include a mechanical life of 50,000 cycles and an electronic life of 10,000 cycles, ensuring long-lasting performance. Low contact resistance (≤50mΩ) and high insulation resistance (≥1000MΩ) guarantee efficient and safe operation. The dielectric strength of 1500VAC for 1 minute provides additional protection against electrical surges.
How Does It Benefit Your Business?
As a factory supplier, we offer wholesale pricing, making our Rocker Switch a cost-effective choice for manufacturers and wholesalers. Fast shipping and excellent customer service ensure a smooth purchasing experience. Upgrade your products with our premium rocker switch and enhance your market competitiveness.
