Description
Product Specifications:
- Max. Current: 1A
- Max. Voltage: 250VAC
- Operating Temperature: -25℃ to +55℃
- Electronic Life: Moment: 10,000 cycles, Alternate: 5,000 cycles
- Mechanical Life: Moment: 50,000 cycles, Alternate: 100,000 cycles
- Insulation Resistance: ≥100MΩ
- Dielectric Strength: 1,500V
- Contact Resistance: ≤50mΩ
- Certification: CQC, CE
Product Advantages:
Our switches stand out with their long electronic and mechanical life, ensuring durability and reliability. With 60 senior engineers and a perfect development process, we can customize the switch to meet your specific needs, whether it’s a different LED configuration or a unique switch combination.
After-Sales Service:
We offer comprehensive after-sales service, including technical support and warranty coverage. As a factory supplier, we can provide competitive pricing and fast delivery times. Choose Yongxing for your pushbutton switch needs and experience the difference in quality and service.
| Contact resistance | ≤50mΩ |
| Insulation resistance | ≥100MΩ |
| Dielectric strength | 1500v |
| Electronic life (cycles) | Moment:10000 Alternate:5000 |
| Mechanical life (cycles) | Moment:50000 Alternate:100000 |
| Operating temperature | 25T55 |
| IP code | IP40 |
| Max.Rating Current&Voltage | 1A/250V AC |
| Certification | CQC, CE |
Why Choose Our Pushbutton Switches?
Our pushbutton switches are designed for durability and reliability, with a long electronic and mechanical life. As a factory supplier, we can offer competitive pricing and custom solutions to meet your specific needs.
What Are the Key Features?
Key features include a 1A/250VAC rating, IP40 protection level, and the ability to customize the switch to your requirements. Our switches are certified by CQC and CE, ensuring quality and safety.
What Are the Applications?
Our pushbutton switches are suitable for a wide range of applications, including industrial control, home appliances, and electronic devices. Their versatility and reliability make them an ideal choice for various industries.
