Description
| Contact Resistance | ≤50mΩ t85 250vac rocker switch |
| Insulation Resistance | ≥1,000MΩ |
| Dielectric Resistance | 1,500V AC , 1 min |
| Electronic life(cycles) | 10,000 cycles electrical switch |
| Mechanical life(cycles) | 50,000 – 100,000 cycles |
| Certification |
CQC , CE , UL , ENEC |
| Max. Rating Current & Voltage (CQC , CE) |
10(3)A 250V AC T85 6(3)A 250V AC T85 electrical switch |
| Max. Rating Current & Voltage (UL) |
15R(3)A 125V AC , 10R(3)A 250V AC 1/3HP 125V AC |
| Max. Rating Current & Voltage (CB , ENEC) |
10(3)A 250V AC T105,6(3)A 250V AC T105 6A 250V AC ,4A 250V AC T105 |
Why Choose Our ENEC Rocker Switch?
Our ENEC Rocker Switch is designed for durability and reliability, making it the perfect choice for home appliances and electrical devices. With a mechanical life of up to 100,000 cycles and an electronic life of 10,000 cycles, it ensures long-lasting performance. The switch operates at a maximum of 6A/10A, 250V AC, and meets international safety standards with CQC, CE, UL, and ENEC certifications.
What Makes Our Switch Stand Out?
Our rocker switch stands out with its low contact resistance (≤50mΩ) and high insulation resistance (≥1000MΩ), ensuring efficient and safe operation. It also has excellent dielectric strength (1500V AC, 1 min), providing additional protection against electrical faults. As a factory supplier, we offer wholesale prices and comprehensive after-sales service, making it a cost-effective and reliable choice for your needs.
Where Can You Use Our Rocker Switch?
Our ENEC Rocker Switch is suitable for a wide range of applications, including home appliances, electrical devices, and industrial applications. Its durable construction and reliable performance make it ideal for use in demanding environments. Choose our factory-direct rocker switch for your next project and experience the difference in quality and value.
