Description
| Max. Rating Current& Voltage | 3A 250V AC |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥100MΩ |
|
Electronic Life (cycles) |
25000 |
| Mechanical Life (cycles) | 50000 |
| Operation temperature | -5℃~+75℃ Rotary Switch |
| Dielectric Stength | 1500V |
| IP code | IP44 |
Why Choose Our Emergency Stop Switch?
Our emergency stop switch stands out for its high quality, durability, and customization options. Made from PA66 material, it ensures longevity and reliability in various industrial and electric control applications. The switch's round head and plug terminal design make it easy to install and use. With options for single pole (SP) or double pole (DP) configurations, it can meet different electrical needs. Additionally, our factory offers wholesale pricing and customization services to better serve our customers.
What Are the Key Features of Our Switch?
Our emergency stop switch has a maximum rating of 3A 250VAC, ensuring excellent electrical performance. It has a low contact resistance (≤50mΩ) and high insulation resistance (≥100MΩ) for safety and efficiency. With an electronic life of 25,000 cycles and a mechanical life of 50,000 cycles, it can withstand heavy use. The switch operates within a wide temperature range (-5°C to +75°C) and has a high dielectric strength (1500V) and IP44 rating for protection against dust and water.
Can We Customize the Switch to Meet Specific Needs?
Yes, we offer customization options for our rotary switches to meet specific customer needs. Our factory has 60 senior engineers, an injection molding workshop, a 5S production workshop, and perfect development processes to ensure top-notch quality and service. Whether you need a different color, size, or functionality, we can work with you to create a switch that meets your exact requirements.
