Factory Wholesale KCD1 6-Position 16A 250VAC LED Rocker Switch Supplier

Name: Factory Wholesale KCD1 6-Position 16A 250VAC LED Rocker Switch Supplier
SKU: 56290
Availability: InStock

Category: KCD1 series Rocker Switch Tags: 16A 250VAC, Factory Wholesale, KCD1, Rocker Switch, Supplier

1,000 - 4,999 pieces
$0.70

5,000 - 7,999 pieces
$0.65

>= 8,000 pieces
$0.60

Rated 0 out of 5

0 reviews

Factory Wholesale KCD1 LED Rocker Switch – 16A 250VAC, Supplier Direct

Description
Specification

Description

Introducing our high-quality KCD1 6-position 16A 250VAC LED rocker switch, available for wholesale directly from our factory. As a trusted supplier, we offer this versatile switch, perfect for cars and industrial applications. Made from durable plastic with a sleek black housing, it features 6 pins, an ON-OFF switch action, and a DPDT circuit description. With a maximum current rating of 16A and a voltage rating of 250V AC, this switch is built to last. Its IP41 rating ensures protection against dust and water, making it suitable for various environments. The switch boasts a mechanical life of up to 100,000 cycles and an electronic life of 10,000 cycles, guaranteeing reliability and longevity. It comes with multiple certifications, including CQC, CE, UL, ENEC, and CB, ensuring compliance with international standards. Our factory-direct pricing and wholesale availability make this switch an excellent choice for bulk buyers looking for a reliable and cost-effective solution. Contact us today to place your order!

Contact Resistance	≤50mΩ
Insulation Resistance	≥1,000MΩ
Dielectric Resistance	1,500V AC , 1 min
Electronic life(cycles)	10,000 cycles
Mechanical life(cycles)	50,000 – 100,000 cycles
Certification	CQC , CE , UL , ENEC , CB
Max. Rating Current & Voltage (CQC , CE)	16(4)A 250V AC T85
Max. Rating Current & Voltage (UL)	16R(4)A 250V AC , 16R(4)A 125V AC 1HP 125V AC
Max. Rating Current & Voltage (CB , ENEC)	16(4)A 250V AC T125,10(4)A 250V AC T125 16(4)A 250V AC T85,16A 250V AC

Why Choose Our KCD1 LED Rocker Switch?

Our KCD1 LED rocker switch stands out with its high-quality construction, durability, and versatility. Perfect for cars and industrial applications, it offers reliable performance and longevity. The LED indicator provides clear visual feedback, making it easy to use in various environments.

What Are the Key Features?

Key features include a 6-position design, 16A 250VAC rating, IP41 protection, and a DPDT circuit. It also boasts a mechanical life of up to 100,000 cycles and an electronic life of 10,000 cycles, ensuring reliability over time.

How Can It Benefit Your Business?

As a factory supplier, we offer wholesale pricing, making it a cost-effective solution for bulk buyers. The switch's compliance with international standards and multiple certifications ensure peace of mind. Contact us today to learn more about how this switch can benefit your business.

Additional information

Max. Current	16A
Max. Voltage	250V AC
Place of Origin	Shanghai, China
Brand Name	SK(Shangkai)
Model Number	KCD1
Application	Cars, Industrial
Material	plastic
Pins	6pin
Whether the smart	NO
Mechanical Life	100,000 cycles
IP level	IP41
Switch Action	ON-OFF
Termination Type	pin
Name	hot selling 6 pin 16a 250v kcd1 106 rocker switch
Housing Color	black
Circuit Description	DPDT
Contact Resistance	≤50mΩ
Insulation Resistance	≥1000MΩ
Dielectric Strength	1500V AC , 1min
Electronic Life(cycles)	10,000 cycles
Operating Temperature	T55,T85,T125
