Factory Wholesale KCD2 Rocker Switch with Light | High-Quality Supplier

>= 10  pieces
$0.39

0 reviews

Factory Wholesale KCD2 Rocker Switch with Light – High-Quality Supplier

Description

Introducing our KCD2 Rocker Switch with Light, a premium product designed for baby carriers and various industrial applications. As a direct factory supplier, we offer wholesale prices on this high-quality switch. It features a red actuator and a white housing, combining durability with a sleek design. The switch is rated at 16A 250V AC, ensuring reliable performance under demanding conditions. With a mechanical life of 100,000 cycles and an electronic life of 10,000 cycles, it outlasts many competitors. The switch is also IP40 rated, providing protection against dust and small objects. Its ON-OFF switch action and solder termination type make installation straightforward. Our switch stands out with its low contact resistance (≤50mΩ) and high insulation resistance (≥1,000MΩ), ensuring safety and efficiency. The operating temperature range (T55, T85, T125) and dielectric strength (1500V AC 1min) further enhance its reliability. Ideal for industrial, automotive, marine, and off-road vehicle applications, this switch is a versatile and cost-effective solution. We offer comprehensive after-sales support, ensuring your satisfaction. Choose us for quality, reliability, and wholesale pricing.
contact resistance
≤50MΩ
operating temperature
T55 T85 T125
insulation resistance
≥1000MΩ
electronic life(cycles)
10000
dielectric strength
1500V AC 1min
max.rating current & voltage
16(4)A 250V AC

Electronic component device for cross-border e-commerce


Why Choose Our KCD2 Rocker Switch with Light?

Our KCD2 Rocker Switch with Light is a top choice for baby carriers and industrial applications due to its high quality and reliability. As a factory supplier, we offer wholesale pricing, making it a cost-effective solution for your needs.

Key Features and Benefits

The switch features a red actuator and white housing, combining durability with a sleek design. It is rated at 16A 250V AC, ensuring reliable performance under demanding conditions. With a mechanical life of 100,000 cycles and an electronic life of 10,000 cycles, it outlasts many competitors. The low contact resistance (≤50mΩ) and high insulation resistance (≥1,000MΩ) ensure safety and efficiency.

Versatile Applications

Ideal for industrial, automotive, marine, and off-road vehicle applications, this switch is a versatile solution. Its IP40 rating provides protection against dust and small objects, while the ON-OFF switch action and solder termination type make installation straightforward. Choose us for quality, reliability, and wholesale pricing.

Push Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch Customized

Additional information

Max. Current

16A

Max. Voltage

250V AC

Place of Origin

Shanghai, China

Brand Name

Yong Xing

Model Number

KCD2-21N-CA1A-W-R-01-AC220

Application

Industrial, Cars, MARINE, BUSES, electric equipment, off-road vehicles

Material

plastic

Pins

4P

Whether the smart

NO

Mechanical Life

100,000 cycles

IP level

IP40

Switch Action

ON-OFF

Termination Type

solder

Contact Resistance

≤50m Ω

Insulation Resistance

≥1,000MΩ

Electronic Life(cycles)

10000cycles

operating temperature

T55 T85 T125

dielectric strength

1500V AC 1min
