Description
|
item
|
value
|
|
Place of Origin
|
Shanghai, China
|
|
Brand Name
|
SK(shangkai) Yongxing
|
|
Model Number
|
KCD3-11-CB1C-R-R-01
|
|
Current Rating
|
10(3)A
|
|
Voltage Rating
|
250V AC
|
|
Mechanical Life
|
50000 Cycles
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥1000MΩ
|
|
Dielectric Strength
|
1500VAC 1 Minute
|
|
Electronic Life (cycles)
|
10,000
|
|
Certificate
|
CB ENEC17 ROHS
|
|
Circuit
|
SPST
|
|
Dimension Code
|
B1 ( 21.4x15x15.2 , 19.3×13.2×12.9)
|
|
Contact Piece Code
|
B (8 length, 4.8×0.8 standard)
|
|
Actuator Color
|
Red,Yellow,Green,Black,Blue,Orange,White,Gray
|
|
Switch Function
|
On Off
|
Key Features and Benefits
Our KCD3 10A 250VAC 3-Position Rocker Switch offers a range of features that make it an excellent choice for your electrical control needs. With a high mechanical life of 50,000 cycles and an electronic life of 10,000 cycles, this switch ensures long-lasting reliability. Its excellent contact resistance (≤50mΩ) and insulation resistance (≥1000MΩ) provide superior electrical performance, reducing the risk of failure and ensuring safe operation. The switch is also available in a variety of actuator colors, allowing you to customize it to match your design requirements.
Why Choose Our Factory-Direct Switch?
As a factory supplier, we offer competitive pricing and flexible wholesale options, making it easy for you to stock up on this essential component. Our switches are manufactured to the highest standards, ensuring quality and reliability. Additionally, our switches come with CB, ENEC17, and ROHS certifications, guaranteeing safety and compliance with international standards. By choosing our factory-direct KCD3 Rocker Switch, you can be confident that you are getting a high-quality product at a great price.
Applications and Uses
Our KCD3 Rocker Switch is perfect for a wide range of applications, including electrical control, appliance switching, and industrial equipment. Its robust design and high-performance specifications make it suitable for use in demanding environments. Whether you are looking for a switch for your home appliances or industrial machinery, our KCD3 Rocker Switch is an excellent choice. Choose our factory-direct switch for quality, reliability, and value.
