Description
|
item
|
value
|
|
Place of Origin
|
Shanghai, China
|
|
Brand Name
|
SK(shangkai) Yongxing
|
|
Model Number
|
KCD3-11-CF1E-B-B-02
|
|
Max. Current
|
6A
|
|
Max. Voltage
|
250V AC
|
|
Mechanical Life
|
50000 Cycles
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥1000MΩ
|
|
Dielectric Strength
|
1500VAC 1 Minute
|
|
Electronic Life (cycles)
|
10,000
|
|
Certificate
|
CB ENEC17 ROHS
|
|
Circuit
|
SPST 2 Pin On Off Rocker Switch
|
|
Dimension Code
|
F1, 19.3x13mm mounting hole size
|
|
Contact Piece Code
|
E, 4.8×0.8x3mm right angle
|
|
Lamp voltage
|
No lamp
|
|
Function
|
On-Off SPST rocker switch
|
Why Choose Our KCD3 Rocker Switch?
Our KCD3 rocker switch stands out for its high quality, durability, and reliability. With a mechanical life of 50,000 cycles and an electronic life of 10,000 cycles, it ensures long-lasting performance in various electric equipment. The switch is manufactured in Shanghai, China, by our factory, ensuring strict quality control and competitive pricing. As a factory-direct supplier, we offer wholesale prices and excellent after-sales service, making it a cost-effective choice for your projects.
What Are the Key Features of Our KCD3 Rocker Switch?
The KCD3 rocker switch features a maximum current of 6A and a maximum voltage of 250V AC, making it suitable for a wide range of applications. It has a contact resistance of ≤50mΩ, insulation resistance of ≥1000MΩ, and dielectric strength of 1500VAC for 1 minute, ensuring excellent safety and reliability. The F1 dimension code with a 19.3x13mm mounting hole size and E contact piece code with a 4.8x0.8x3mm right-angle design make it easy to install and compatible with various equipment.
How Does Our KCD3 Rocker Switch Benefit Your Business?
By choosing our KCD3 rocker switch, you benefit from a high-quality, reliable product that meets international quality standards. Certified with CQC, CE, UL, CB, ENEC17, and ROHS, it ensures safety and compliance in your applications. As a factory-direct supplier, we offer competitive wholesale prices, reducing your procurement costs. Additionally, our excellent after-sales service ensures your satisfaction and peace of mind, making it a wise investment for your business.
