Factory Wholesale Micro Switch Supplier – Normally Open for Home Appliances

Category: Tags: , ,
$0.39
0 reviews

Factory Wholesale Micro Switch Supplier – High Quality for Home Appliances

Description

Welcome to our factory-direct wholesale micro switch supplier! Our KW11 model micro switch, designed with a straight press bar, is perfect for small home appliances. This switch is CE and ENEC17 certified, ensuring top-notch quality and safety. With IP40 and IP65 protection levels, it’s suitable for various environments. The switch operates within a wide temperature range of -25°C to +125°C, and can handle currents from 1A to 16A and voltages from 125V to 250V. It boasts a contact resistance of ≤50mΩ, insulation resistance of ≥100mΩ, and a dielectronic strength of 1,500V, ensuring reliable performance. With an electronic life of 50,000 cycles, it’s built to last. Our factory, located in Shanghai, China, is equipped with advanced facilities and a team of 60 senior engineers, ensuring we can develop switches tailored to your needs. We offer competitive wholesale prices and excellent after-sales service. Contact us today to discuss your requirements!
IP IP40 , IP65
Color Black
Current 1A~16A
Voltage 125V~250V
Contact Resistance ≤50mΩ
Insulation Resistance ≥100mΩ
Dielectronic Strength 1500V
electronic life(cycles) 50,000
operating temperature -25℃~+125℃
Certification ENEC , UL , CQC

Electronic component image for cross-border e-commerceElectronic device image for e-commerce websiteElectronic part image for cross-border salesElectronic accessory image for e-commerce optimization


Why Choose Our Micro Switch?

Our micro switch stands out for its high quality, reliability, and versatility. With CE and ENEC17 certifications, it meets international safety standards. The wide operating temperature range and robust electrical specifications make it suitable for a variety of applications, from home appliances to industrial equipment.

Factory Direct Wholesale Advantage

As a factory-direct supplier, we offer competitive wholesale prices without compromising on quality. Our in-house production facilities and experienced engineering team allow us to customize switches to your specific requirements, ensuring you get exactly what you need.

After-Sales Service

We pride ourselves on providing excellent after-sales service. If you encounter any issues or have questions about our products, our dedicated support team is here to help. We strive to build long-term relationships with our customers by ensuring their satisfaction.

Push Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch Customized

Additional information

Whether the smart

NO
Max. Current

5A
Max. Voltage

250V AC
Place of Origin

Shanghai, China
Brand Name

SK(Shangkai)
Model Number

KW11
Operating Temperature

-15°-+125°
Name

3 pin 1a 125vac push off touch vt16021c2 ms4 electronic micro switch
Color

Black
Current

1A~16A
Contact Resistance

≤50mΩ
INSULATION RESISTANCE

≥100mΩ
dielectronic strength

1,500V
electronic life(cycles)

50,000
operating temperature

-25℃~+125℃
Certification

ENEC , UL , CQC
IP

IP40 , IP65
Protection Level

IP40 , IP65
