Description
Key specifications include a contact resistance of ≤50mΩ, insulation resistance of ≥100mΩ, dielectric strength of 1500V, and an electrical life of 10,000 cycles. The switch operates within a temperature range of -25℃ to +85℃, making it suitable for harsh environments.
As a factory supplier, we offer wholesale pricing and bulk discounts. Our switches are CQC, CE, ROHS, and ISO9001 certified, ensuring compliance with international standards. The black color and compact size (22mm) make it a versatile choice for different applications.
Choose our factory-direct push button switch for quality, reliability, and cost-effectiveness. We provide excellent after-sales service and technical support to ensure your satisfaction.
|
item
|
value
|
|
Place of Origin
|
Shanghai(China)
|
|
Brand Name
|
SK(Shangkai)
|
|
Model Number
|
KA13
|
|
Protection Level
|
IP40
|
|
Max. Current
|
10A
|
|
Max. Voltage
|
250V AC
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥100MΩ
|
|
Dielectric Strength
|
1500V
|
|
Electrical Life
|
10000times
|
|
Operating temperature
|
-25℃~+85℃
|
|
Certificate
|
CQC CE ROHS ISO9001
|
|
Color
|
black
|
Why Choose Our Momentary Push Button Switch?
Our push button switch stands out for its high quality, reliability, and cost-effectiveness. With a 10A 250VAC rating and IP40 protection, it's suitable for a wide range of industrial and commercial applications. The momentary action ensures precise control, while the high electrical life guarantees long-term durability.
What Are the Key Features of Our Switch?
Key features include a contact resistance of ≤50mΩ, insulation resistance of ≥100mΩ, and dielectric strength of 1500V. It operates within a temperature range of -25℃ to +85℃, making it ideal for harsh environments. The compact size (22mm) and black color make it versatile and easy to integrate into various systems.
Why Buy from Our Factory?
As a factory supplier, we offer wholesale pricing and bulk discounts. Our switches are CQC, CE, ROHS, and ISO9001 certified, ensuring compliance with international standards. We provide excellent after-sales service and technical support to ensure your satisfaction. Choose us for quality, reliability, and cost-effectiveness.
