Description
| Panel Thickness | 1-10mm |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥1000 MΩ 4 pin push button switch |
| Torque | 5-14Nm |
| Operating Pressure | About 4N |
| Operating Stroke | About 1.8mm |
| Mounting Hole Size | 22mm |
| Dielectric Strength | 2000VAC |
| Electronic Life | >1,000,000 times |
| Mechanical Life | >200,000 times |
| Operating temperature | -20°c~+55°c |
| IP code | IP67 IK09 |
| Switch Rating | 2A /36VAC emergency push button switch |
| Contact Configuration | 1NO |
| Operating Type | Momentary elevator push button switch |
| The Front Shape | High Round |
| The Crust Material | Stainless Stell,Nickel-plated Brass or Gold-Plated Brass |
|
Material |
Contact : Sliver Alloy (Can be made to order) |
Why Choose Our Stainless Steel Push Button Switch?
Our stainless steel push button switch stands out for its durability, reliability, and affordability. As a factory supplier, we offer wholesale pricing, making it an excellent choice for bulk purchases. The switch is designed to handle demanding electrical loads, with a maximum current of 5A and voltage of 250V, ensuring safe and efficient operation.
What Makes Our Switch Durable?
The switch features a contact resistance of ≤50MΩ, insulation resistance of ≥1000MΩ, and dielectric strength of 2000VAC, contributing to its long-lasting performance. Its IP67 rating guarantees protection against dust and water, making it suitable for harsh environments. Additionally, the switch has a mechanical life of over 1,000,000 times and an electrical life of over 200,000 times, ensuring reliability over time.
What Are the Available Options and Customizations?
Our push button switch is available in 16mm, 19mm, and 22mm sizes, with various switch combinations including 1NO1NC, 1NO, 2NO2NC, and 2NO. It also comes with LED indication for easy visibility. We offer customizations to meet specific requirements, ensuring the switch fits perfectly into your application.
