Factory Wholesale Waterproof 3A 5A 3-Pin Micro Limit Switch Supplier

200 - 1,999  pieces
$0.35

2,000 - 4,999  pieces
$0.31

>= 5,000  pieces
$0.27

0 reviews

Factory Wholesale Waterproof Micro Limit Switch Supplier – High Quality, Durable

Description

Our factory-direct Waterproof 3A 5A 3-Pin Micro Limit Switch is a top-notch product designed for electronic machines. With a contact resistance of ≤50MΩ and an insulation resistance of ≥100MΩ, it ensures reliable performance. This switch can withstand a dielectric strength of 1500V and operates within a temperature range of -25℃ to 125℃. It has a maximum rated current of 3(3)A and a voltage of 250V AC. The mechanical life is an impressive 100,000 times, and the electronic life is 50,000 cycles. Made of durable plastic, it is IP40 rated for waterproof protection. Ideal for industrial, electric power, household, and telecommunication applications, our micro limit switch stands out for its high quality and longevity. As a trusted supplier, we offer wholesale pricing and excellent after-sales service. Choose us for your micro limit switch needs and experience the difference.
contact resistance
≤50MΩ
electronic life(cycles)
50000
insulation resistance
≥100MΩ
operating temperature
25T125
dielectric strength
1500V
max.rated current & voltage
3(3)A 250V AC

Electronic component product image for cross-border e-commerce


Why Choose Our Waterproof Micro Limit Switch?

Our waterproof micro limit switch is designed to withstand harsh environments, making it ideal for industrial, electric power, household, and telecommunication applications. With a high insulation resistance and dielectric strength, it ensures safe and reliable operation. The long mechanical and electronic life means fewer replacements, saving you time and money.

What Are the Key Features?

This switch features a 3-pin design, a maximum rated current of 3(3)A, and a voltage of 250V AC. It is IP40 rated for waterproof protection and has a durable plastic construction. The switch operates within a wide temperature range, from -25℃ to 125℃, ensuring performance in various conditions.

Why Buy from Us as a Supplier?

As a factory-direct supplier, we offer wholesale pricing and excellent after-sales service. Our products are of high quality and undergo rigorous testing to ensure they meet or exceed industry standards. Choose us for your micro limit switch needs and experience the difference in quality and service.

Push Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch Customized

Additional information

Whether the smart

NO

Max. Current

3(3)A

Max. Voltage

250V

Place of Origin

Shanghai, China

Brand Name

Yong Xing

Model Number

KW11-12-A1FA-B

Application

Industrial, electric power, households, Telecommunication

Material

plastic

Mechanical Life

100000 times

Circuit

SPDT

Operating Temperature

-25℃ to 125℃

IP level

IP40

color

black

IP code

IP40

contact resistance

≤50MΩ

insulation resistance

≥100MΩ

electronic life(cycles)

50000
