Description
|
Contact resistance |
≤50mΩ |
|
Insulation resistance |
100MΩ |
|
Dielectric strength |
KMB(normal):1500v KBM-A(sector):1000v |
|
Electronic life (cycles) |
10000 cycles |
|
Mechanical life (cycles) |
50000 cycles |
|
Operating temperature |
-25℃~+55℃ |
|
IP code |
IP40 |
|
Max.Rating Current&Voltage |
KMB(normal):2A/250V AC KBM-A(sector):4A/250V AC |
|
Certification |
CQC, CE |
Why Choose Our Refrigerator Door Switch?
Our refrigerator door switch stands out for its high quality, durability, and customization options. As a factory and direct supplier, we offer competitive wholesale pricing and ensure timely delivery. With certifications like CQC, CE, and RoHS, our switch guarantees safety and compliance, making it the ideal choice for refrigerator manufacturers and repair shops.
Key Features of Our Switch
Our switch boasts a contact resistance of ≤50mΩ, insulation resistance of 100MΩ, and dielectric strength of 1500V (KMB) or 1000V (KBM-A). It operates efficiently within a temperature range of -25℃ to +55℃ and has a long mechanical life of 50,000 cycles and an electronic life of 10,000 cycles. These features ensure reliable performance and longevity.
Customization and Support
We understand that every customer has unique needs. That's why we offer customization options to tailor the switch to your specific requirements. Our 60 senior engineers and 5S production workshop ensure that we can meet even the most demanding specifications. Additionally, our dedicated support team is always available to assist you with any questions or concerns.
