Description
|
contact resistance
|
≤50MΩ
|
electronic life（cycles）
|
10000
|
|
insulation resistance
|
≥100MΩ
|
mechanical life（cycles）
|
50000
|
|
IP code
|
IP40
|
operating temperature
|
25T55
|
|
dielectric strength
|
1500V AC 1min
|
max.rating current & voltage
|
1A 250V AC
|
Why Choose Our Momentary Push Button Switch?
Our momentary push button switch stands out for its high-quality plastic construction, ensuring durability and longevity. With a max. rating current of 1A and max. voltage of 250V AC, it's suitable for a wide range of electrical applications. The 1NO1NC switch combination offers flexibility in circuit design.
What Are the Key Features?
Key features include an IP40 protection level, 50,000 electronic and mechanical life cycles, and an insulation resistance of ≥100mΩ. These features ensure reliable performance and safety in various environments.
Why Buy from Us as a Wholesale Supplier?
As a factory-direct wholesale supplier, we offer competitive pricing and high-quality products. Our switches are manufactured in Shanghai, China, ensuring strict quality control. Choose us for unbeatable value and excellent customer service.
